LC1000 series intelligent production line controller, small size, high performance, strong operation control, built-in UPS power failure protection function, low power fanless design, LCD improve the ease of debugging and maintenance, high-speed 8DI+8DO to complete the fly-beat, fly-shear and latch functions, with strong shaft capability, short bus cycle, easy to achieve various motion control. Help the intelligent "intelligent manufacturing" industry to reduce costs and increase efficiency
LC1000 series intelligent production line controller, small size, high performance, strong operation control, built-in UPS power failure protection function, low power fanless design, LCD improve the ease of debugging and maintenance, high-speed 8DI+8DO to complete the fly-beat, fly-shear and latch functions, with strong shaft capability, short bus cycle, easy to achieve various motion control. Help the intelligent
"intelligent manufacturing" industry to reduce costs and increase efficiency, transformation and upgrading.
■ Core advantages
Strong performance
1. CPU quad-core 2.0GHz
2. Up to 128 axes
3. Maximum execution efficiency is 1ns
4. The effective accuracy of 250us cycle is increased by 30%
informatization
1. OPC UA is directly connected to the IT information system
2. Standardized EtherNet/IP networking
3. High-level language API/Web visualization
4. ModBus/Socket communication
integration
1. Integrate rich hardware interfaces
2. Integrated rich operation and control functions:
ø6-axis straight line / 3-axis arc forward interpolation
Ø Robot forward and inverse kinematics transformation
Ø Electronic wheel /CNC/ shaft set
Ø High speed position latch/fly beat
Save space
1. Small body, help to miniaturize the control cabinet
2. Two installation methods: card rail installation, back mounting
ear fixed installationSave time
1. Programming software LeadSys is easy to debug and saves programming time
2. Integrate industry process algorithm to shorten equipment development time
3. LCD diagnostic display, reduce debugging and operation maintenance time
4. EtherCAT redundant ring network, star network, reduce unplanned downtime
Cost saving
1. Integrate a variety of communication interfaces to save
external communication modules2. Integrated high-speed IO, saving IO modules
3. Built-in UPS to reduce the cost of external UPS
