At present, the application fields of industrial computers are constantly expanding, such as automation, digitalization, intelligent upgrading of key businesses in industries such as industry, electricity, environmental protection, transportation, medical care, logistics, finance, and government affairs increasingly rely on industrial computers for data processing and process control, which has spawned the rapid growth of the domestic industrial computer industry.
At present, the application fields of industrial computers are constantly expanding, such as automation, digitalization, intelligent upgrading of key businesses in industries such as industry, electricity, environmental protection, transportation, medical care, logistics, finance, and government affairs increasingly rely on industrial computers for data processing and process control, which has spawned the rapid growth of the domestic industrial computer industry. At the same time, the realization of key technologies and products in important scientific and technological fields has become a trend, and the huge space for domestic substitution in the industrial computer market has
gradually emerged.
In this situation, North China Industrial control has strengthened the friendly cooperation with domestic CPU enterprises such as Fiiteng, Ruixin Micro, Hisilicon, Zhaoxin, Haiguang, Longxin, and so on, and innovated to create a domestic industrial control product solution, and launched a series of industrial control motherboards with high localization rate and high performance, embedded quasi-system/machine and industrial tablet computers to serve users in multiple industries. For example, North China Industrial Control based on the domestic CPU Dragon son 7A1000 industrial control product solutions, from computer hardware to product drivers, operating systems have
great autonomy, in data computing, caching, network communication, I/O scalability and durability and other aspects are also excellent, can meet the multi-industry user's application needs for autonomous controllable industrial computer products.
MITX-6112 Industrial control board is one of the products built by North China Industrial Control based on the domestic CPU Loongson 7A1000 chipset. Its main performance is as follows:
· Support Loongson 7A1000 chipset and LS3A4000 processor, support up to 2.0GHz, excellent data computing capability;
∙ Integrated vulnerability prevention design, hardware national secret algorithm, secure trusted module and secure access control mechanism;
∙ Built-in power control core, which can dynamically adjust frequency and voltage according to the operating load, thus achieving fine power management;
· Loongson self-developed BIOS, deeply adapted to the Linux system, and
developed a watchdog function to provide a more secure and stable system operating environment;
∙ CPU integrated graphics controller, support 2*VGA display interface, support resolution up to 1920*1080;
∙ Supports 2*UDIMM slots, DDR4 2400Mhz, and up to 32GB operating memory;
∙ Support for 2*SATA (SATA 2.0) interface and 1*M.2 M KEY 2280 (NVME protocol only) interface to further expand storage capacity;
∙ Support 2* adaptive Gigabit RJ45 Ethernet port, 1*SIM card slot and 1*Mini-PCIe extended WIFI/3G/4G network module;
∙ Support 4*USB3.0, 11*USB2.0 to realize the interconnection of multiple smart devices;
∙ Support 2*RS-232 interface to achieve high rate data transmission;
∙ Support 1*Line-out, 1*Mic-in, 1*Line-in, 1*AMP audio interfaces;
∙ Support 1*PCIe 16x Slots and 4*PCIe x1 signals for multiple expansion;
∙ Support 1*PS2, 1*JFP, 1*LPC, 1*CPU FAN to meet more
peripheral access requirements;· Support 8*GPIO Input/Output programming;
∙ Support ATX power supply, and meet the requirements of 0℃ ~ 60℃ wide temperature operation;
• Size 170mm x 170mm, highly integrated and easy to deploy.
In addition, based on the MITX-6112 motherboard, North China Industrial Control also launched two desktop embedded quasi-system EPC-3132LX-A and EPC-3132LX-B, which also support the domestic CPU Loongson 7A1000 to achieve autonomous control, and further improve the I/O expansion capability and rugged characteristics. Active cooling design for performance and power consumption, suitable for
multiple scenarios.
As an industry-specific embedded computer product provider, North China Industrial Control has been committed to providing customers with X86 architecture and ARM architecture diversified embedded motherboards, embedded quasi-systems/complete machines and industrial tablet computer products and services, from computer hardware to operating systems, product drivers, security software are supporting
customer customized development.
