Embedded computer has become an important component of the development of digital economy, serving industrial automation, smart medical, smart city and other fields, showing a high demand. With the development of digital and intelligent transformation in various industries, embedded computer products are also increasingly pursuing multi-performance integration, multi-tasking, fast response, flexible expansion, high security and high reliability and other technical characteristics to meet the needs of various commercial/industrial environment applications.
Following the development trend, North China Industrial Control continues to innovate and develop embedded computer products. Based on the Intel Core processor of 12/13/14 generation, North China Industrial Control has launched a highly integrated embedded motherboard ATX-6152, which provides excellent performance and rich I/O interfaces, and has high security and stability, and is suitable for multiple scenarios.
01 Supports 12/13/14-generation Intel Core processors
North China Industrial Control ATX-6152 supports 12/13/14 generation Intel Core i3/i5/i7/i9 processor and Intel Q670E/Z690 chipset, TDP up to 125W, maximum 24 core 32 threads, Rui frequency up to 5.8GHz, The performance-based hybrid architecture meets the needs of multitasking and complex computing.
Integrated display supports Intel Torch ® Xe graphics and Intel ® Hypercore graphics (model depends on CPU processor); Support 1*VGA, *HDMI, 2*DP++ interfaces to achieve independent multi-display and the highest 4K resolution display; Supports 1*PCIe x16(16-lanes) slots for mechanical installation of large graphics cards, providing better image processing performance.
The bandwidth and storage capabilities of the ATX-6152 are further optimized, supporting 4*UDIMM memory slots, supporting DDR5 4800MHz, and up to 128GB of operating memory on the entire board. It also supports 4*SATA 3.0 and 1*M.2 M KEY 2280 PCIe x4(GEN4) NVME SSDS for cache and storage capacity expansion.
02 Rich I/O interface and highly integrated design
North China Industrial Control ATX-6152 is equipped with a variety of communication ports, including 2* Gigabit RJ45 network port, 1*SIM, and 1* M.2B Key 3042/3052 port for 4G/5G module. In order to improve wireless network performance, reduce network latency and achieve a higher degree of integration, the ATX-6152 supports the 1*M.2 E Key 2230 interface to connect to the Wifi/ Bluetooth /CNVI module by integrating key network functions into the processor.
Support 8*RS232, 2*RS232/RS422/RS485 interface to meet the long/short distance higher rate data transmission and processing requirements, And 4*USB3.2x1 GEN2(10 Gbps), 5*USB3.2x1 GEN1(5 Gbps), 3*USB2.0 interface can realize the interconnection of multiple smart devices.
The ATX-6152 also supports 2*Line out, 2*Mic in, 1*Line in, and 1*AMP audio interfaces. Supports 1*PCIe x4(1-lane) GEN3, 3*PCIe x4(4-lanes) GEN3, 1*PCIe x4(4-lanes) GEN4, 1*PCIe x8(4-lanes) GEN3 slots, And 8*GPIO, 1*CPUFAN, 1*SYSFAN, 1*JFP, 1*PS/2 interface for users to achieve more peripheral access.
03 Provides reliable security and stability
North China Industrial Control ATX-6152 compatible with Windows 10/11, Linux operating system, developed a watchdog function, and support Intel AMT and Intel vPro Technology based on dedicated hardware security enhancement function (with the Z690 bridge does not support AMT function), can provide users with a more secure and reliable system operating environment.
The size is 305mmx 244mm, the standard ATX 24Pin +8Pin power supply mode makes the output more stable, meets the wide temperature operating conditions of 0℃ ~ 60℃, and has industrial durability such as electromagnetic interference resistance, suitable for multiple scenarios.
