Harting introduces the new M12 IDC x-code product, the first connector in Harting's M12 circular portfolio to feature an IDC termination (insulated puncture connection) with performance up to 10 Gbit/s. The tool-free connector series can be well used in automation fields such as: industrial Ethernet switches, PLCS, camera systems for process monitoring or other typical industrial fields and applications where high data transfer is the most advanced.
Harting introduces the new M12 IDC x-code product, the first connector in Harting's M12 circular portfolio to feature an IDC termination (insulated puncture connection) with performance up to 10 Gbit/s. The tool-free connector series can be well used in automation fields such as: industrial Ethernet switches, PLCS, camera systems for process monitoring or other typical industrial fields and applications where high data transfer is the most advanced.
The product release includes field joinable male and female connectors with threaded locking mechanisms and push-pull locking mechanisms compliant with IEC 61076-2-010.
Benefits of M12 IDC x-code
Products comply with IEC 61076-2-109 and IEC 61076-2-010 push-pull locking mechanisms
X-coding mating face, 8 contacts
48 V AC rated voltage, 0.5A, CAT.6A
Insulation puncture cable IDC, AWG26-AWG23
Male and female versions with threaded and push-pull locking mechanisms
Fully masked version
Meets IP 65/67 protection class, complies with IEC 60529 standard, and has a temperature range of -40°C to 85°C
The outer diameter of the cable is 5.1mm to 10.5mm
Vibration shock protection complies with IEC 61373 Cat.1B
Product ordering information
Application field
PLC
Industrial Ethernet switch
Industrial wireless access point
Servo driver
Robot technology
Mechanical Engineering/Industrial Machinery
