main
Product range: Modicon Momentum Automation platform
Product or component type: Discrete input base DC
Channel group: 2 groups, each group 16 inputs
Discrete input number: 32IEC1131-2 Type 1
Discrete input voltage: 24V DC
Protective therapy: TC series
Schneider Electric's 170AD135000 I0 module comes from its renowned Modicon communication family and Modicon Momentum automation platform. Over the years, Schneider Electric - has been producing efficiently and efficiently
We pride ourselves on high quality, user-friendly products. This special discrete input basic I/O module is no different and will definitely get the job done!
An adaptive I/O module such as this can work with a long string of communication adapters that provide interfaces to connect the I/O base to a variety of open communication networks that comply with _ I industry standards. The following communication adaptations
The device is available for 170ADI35000 I/O modules :ControlNet, DeviceNet, Ethernet, FIPI/O, InterBus, Modbus Plus (IEC data format or 984 data format) and Profibus-
DP.
In addition to communication adapters, the family's /O modules are compatible with a large number of processor adapters or programmable logic controllers (PLCS). This special type of adapter can be easily installed in any Momentum
On the I/O pedestal, as the local I/O controls its point. Overall, the processor adapter is responsible for saving and propagating logic programs and controlling I/O points on a specific communication bus.
Another type of adapter, called an optional adapter, is designed to work with a processor adapter and an I/O dock. Optional adapters allow users to configure additional communication ports, clocks, and/or spare batteries.
Optional adapters The following communication ports can be configured: one user-optional RS-232 /RS-485 port, one Modbus Plus port, and/or two (redundant)Modbus Plus ports.
The 170ADI35000 discrete input module is a module for receiving and processing discrete signals, usually used in industrial automation, measurement and control systems and other fields. Its main functions and features include:
Signal acquisition: Various discrete signals can be collected, such as switching quantity, digital quantity, etc.
Anti-interference ability: 170ADI35000 has strong anti-interference ability and can work stably in harsh industrial environment.
Isolation protection: photoelectric isolation and other technologies are generally used to effectively protect the system from external signal interference.
Programmability: The 170ADI35000 can be programmed to set the processing of the input signal to meet different application requirements.
Easy to expand: multiple discrete input modules can be combined to facilitate the expansion and upgrade of the system.
Fault diagnosis: 170ADI35000 Some discrete input modules also have fault diagnosis function, which can find the abnormal situation of the input signal in time.
These characteristics make the discrete input module widely used in industrial control, automation equipment, monitoring system and other fields, and help to improve the reliability and stability of the system
