Extended product type: TB5600-2ETH
Product ID: 1SAP110300R0278
ABB Model name: TB5600-2ETH
EAN: 4013614508912
Directory Description: Terminal base. For AC500 V3. There is no communication module slot. Two Ethernet ports. 1 serial interface. 1 CAN interface (TB5600-2ETH)
Details: TB5600-2ETH: AC500 terminal base. For AC500 V3. There is no communication module slot. Two Ethernet ports. 1 serial interface. One CAN interface.
Net weight: 0.129 kg
Net product thickness/length: 28 mm
Product height: 135 mm
Product width: 67.5mm
Gross weight: 0.198 kg
Package Grade 1 Depth/Length: 147 mm
Package Grade 1 Height: 40 mm
Package Grade 1 Width: 131 mm
Features:
Provides connection points for the I/O (input/output) modules used in the AC500 PLC system.
Each terminal base can accommodate multiple I/O modules, extending the PLC's capabilities.
Connect to AC500 CPU (Central processing unit) module for communication and data exchange between CPU and I/O module.
Features:
Has a specific number of I/O module slots (for example, 4 slots, 8 slots).
Different types of I/O modules may be supported, such as digital I/O, analog I/O, and communication modules.
Features such as backplane power distribution and status leds for troubleshooting may be included.
Applications:
For a variety of industrial automation applications controlled by ABB AC500 PLC.
Examples include:
Factory automation
Machine control
Building automation
Process control
