The FBM241 contains eight discrete inputs and eight discrete outputs, with voltages and currents commonly found in industrial plants.
summarize
Channel isolation, discrete /o module Depending on the type of /o signal required, TAs(FBM241 1/b/c/d) has 8 discrete input channels containing current limiting devices, fuses, relays or relays with 8 separate output channels. Related output with internal or external power supply and
The terminal component (ta) supports discrete input fusion.
Or output voltage below 60v dc signal;
The module comes in four different types and 120 volts / 125 vdc, or240Vac. Each type and its associated TA are supported
The following are discrete inputs and outputs:
FEATURES
Key features of the FBM241/b/c/d modules are:
Eight discrete inputs
Eight discrete outputs
Supports discrete inputs/output signals at
voltages of:
• 15 to 60 V dc
• 120 V ac/125 V dc
• 240 V ac
Each input and output is galvanically isolated: each input and output is galvanically isolated:
group isolated when used with external excitation
Rugged design suitable for enclosure in Class G3
(harsh) environments
Executes the Discrete I/O or Ladder Logic
program, with the following configurable options:
Input Filter Time, Fail Safe Configuration, FailSafe Fall-Back, and Sustained or Momentary
Outputs
Various Termination Assemblies (TAs) that
contain:
• Current limiting devices
• Fuses
• Relay outputs
• Relay outputs with internal or external power
source and fusing
• Solid state outputs
