DCS card module FBM217 P0914TR Supports redundant dual fiber ring topology

The FBM217 P0914TR is a product under the FOXBORO brand that plays an important role in industrial automation and control systems. The following is a detailed introduction to the FBM217 P0914TR:

First of all, in terms of power supply and protection, the FBM217 P0914TR uses a dual power supply redundancy input design, the power supply range is DC(9-36)V, the typical value is DC24V, and the power consumption is less than 4W. This design ensures the stability and reliability of the power supply, even in the case of a power supply failure, the system can operate normally. In addition, it also has DC1500V voltage isolation and reverse connection protection function, which can effectively prevent damage to the equipment caused by voltage anomalies. At the same time, it uses industrial terminal interface, the connection is more stable and reliable.

In terms of alarm output, the FBM217 P0914TR is equipped with relay alarm output function. When the fiber link or power supply fails, the relay will trigger the alarm output, and the contact capacity is DC48V/1A. This helps to detect and handle system faults in a timely manner to ensure the stable operation of the system.

In terms of communication, the FBM217 P0914TR supports logically independent dual Profibus DP buses and supports predetermined communication rates in the standard specification. It also allows the dip switch to manually set its full standard rate or rate adaptive, providing great flexibility. In addition, the module has 1~2 Profibus DP electrical ports and 1~2 155M optical fiber interfaces, supporting redundant dual network fiber ring network topology, this design increases the redundancy and reliability of the system.

In terms of data transmission, the FBM217 P0914TR has excellent performance. It supports fiber optic distances of more than 20km and reliable transmission of data over long distances with a high-speed optical interface of 155Mb/s. In addition, it is equipped with six two-color LED status indicators to indicate the status of fiber link as well as power failure.

In terms of protection and installation, the FBM217 P0914TR achieves IP30 protection and uses a wavy aluminum reinforced housing, which enhances its resistance to external environment and physical shock. At the same time, it adopts the standard industrial 35mm rail mounting method, which is convenient for users to install and deploy.
