Foxboro (Schneider Electric)
Product number: P0917HA
Product Model :FBM220 HART communication redundant output interface module
Types of HART instruments supported: HART instruments that comply with version 5, 6 or 7 of the Hart specification can be used
Interface :8 isolated output channels
Isolation: Current isolation (optical and transformer isolation) of channels from each other and from ground and module logic. After applying a 600 V AC voltage between the isolated channel and the ground (ground) for one minute, the module can withstand it without damage.
Fieldbus communication: Communication with its associated FCM or FCP via a redundant 2 Mbps HDLC fieldbus
Operating temperature: Modules -20 to +70 ° C (-4 to +158 ° F) Terminal components PVC-20 to +50 ° C (-4 to +122 ° F)
Size :10.4 cm x 4.5cm x 11.4cm
Weight :0.284 kg
Shipping weight :1.5 kg
P0917HA FBM220 Voltage monitor/Contact sensing input module functions as a 16-channel DC voltage monitor or 16-channel contact sensor. Each channel accepts 2-wire input from the DC voltage source P0917HA FBM220 or to a contact or solid-state switch. Related Terminal components (TAs) support discrete input signals at 60v DC, 120v AC/ 125v DC or 240v AC voltages. For voltages above 60vDC, TAs has additional signal conditioning hardware that provides voltage attenuation and optical isolation.
Each discrete input is isolated from other channels and geoelectricity. Use external excitation when groups are isolated.
The module performs the required signal conversion from the field sensor to the electrical input signal interface of the redundant module fieldbus. In addition, it performs programs for discrete inputs, ladder logic, pulse counting, and event sequences, and has configurable options for input filter times.
The module can be used as a single unit or as a redundant pair (two FBM207s). When used as redundant pairs, these modules combine to provide redundancy at the field bus module (FBM) level, where the field input signal is received from a common terminal component via a redundant adapter attached to the FBM mainboard. Input current of the redundant module is doubled. Redundant digital input blocks in the Foxboro Evo™ control software validate each input along with the module's information and select the input of the highest quality for processing in the control strategy. In a redundant configuration, the contact sensing power from each module is diode in a redundant adapter or together to ensure redundant power.
FOXBORO FBM201e | P0924TR | Analog Input Module |
FOXBORO FBM201d | P0922YK | CHANNEL ISOLATED 8 INPUT 0-10 Vdc I/A SERIES |
FOXBORO P0912XX I/A series AC transmission power supply |
FOXBORO P0926GH Input Module Assembly |
FOXBORO RH916ND Termination Module |
FOXBORO P0917JK (supersedes P0916AB) Base terminal |
FOXBORO RH916XG TAs for Compact FBM201 module |
FOXBORO RH916DD (5m) Cable |
FOXBORO P0916FK 18.5ft Length Cable Invensys 18.5' |
