The compact FBM240 is an 8-channel input and 8-channel output FoxboroTM DCS Fieldbus module (FBM) available as a single or redundant module. Redundant pair
These modules are combined to provide redundancy at the FBM level to which field/output connections are made
A common terminal component (see Figure 1). Each module independently holds the output at its specified output value, and each independently reads the observed value of its output.
This module is part of the Compact 200 Series I/0 Subsystem Overview (PSS 41H-2COV). Each output in a redundant contact output block verification in the control software is combined with information from the input/output module.
peculiarity
●8 discrete outputs / 8 discrete voltage monitor inputs
●8 discrete inputs read the voltage through relay contacts. Settings
If the state of the connection is inconsistent with the state of the channel, the corresponding output channel of channel BAD is opened
Monitor each FBM output and set the output channel BAD if the output is in the wrong state
● Single or redundant modules
● Terminal Components (TAs) are used for local or remote connection of field cabling to the compact FBM240
● Support discrete relay output, can be switched :10Aat80 to 120 volts, or
5Aat 80 ~ 125 V dc, or
5Aat 15v to 30v dc, or
5Aat 80 ~ 120v ac
● Discrete I/O for channel isolation:
15-60v DC-@2A, molten output
15 to 60v DC input
