The IC200MDL740B discrete output module is a GE Fanuc 12/24 V DC Versamax positive logic output module with 1 set of 16 source type outputs. It has a rack-mount option and compact design with a hot-plug feature that helps users easily replace it without changing field wiring. The IC200MDL740B discrete output module has an LED to indicate the status of each output point. There are 3 types of carriers that can be used to easily install or replace output modules in the system without interrupting operation. It has a configurable filtering time, a maximum on-off response time of 0.2 ms and a maximum turn-off response time of 1.0 ms. It also provides external power to the load side and works with a backplane power supply.
The IC200MDL740B DC positive logic output module has a set of outputs with DC+ and DC-terminals. The external suppression circuit must be used with the inductive load at the output. The external suppression circuit can be connected to both ends of the actual load or to each output point that drives the inductive load. It is recommended to use a short circuit rod with a 2 amp current carrying capacity on the B terminal to add additional bus terminals. The wide range of brackets allows users to install the correct brackets without using any tools. These easily connected facilities reduce the training time and lifecycle costs required to use this output module. It also comes with configuration software to easily perform hardware and network configuration. The IC200MDL740B Discrete output module is a general-purpose distributed product designed for industrial and commercial automation and industrial control applications.
