8-channel, 12-bit, 60 MHz bandwidth PCI oscilloscope devices - The PCI‑5105 high-density PXI oscilloscope features eight synchronous sampling channels, providing flexible coupling, impedance, voltage range, and filtering Settings. The oscilloscope also has multiple trigger modes, high capacity onboard memory, and an instrument driver that includes data streams and analysis functions. The device is ideal for multi-channel applications that require up to 60 MS /s or 60 MHz analog bandwidth.
The NI PCI-5105 is a high density oscilloscope/digitizer with 8 synchronous sampling channels. It includes a wide input range of 50 mV to 30 V, a software-selectable input impedance of 50 or 1 M, deep onboard memory up to 512 MB, a variety of trigger options, and compact synchronization capabilities. With PCI-5105, users can develop 136 phase-coherent channels in a single PCI body. Users can also program more than 50 built-in estimation and analysis functions directly from the driver and extend them to more than 400 capacities using NI LabVIEW and LabWindows/ CVI software. Other software (such as Measurement Studio, Microsoft Visual C/C++ or. NET) can be used to program the device. This model has three part numbers with different onboard memory capacities: 779686-01 (16 MB), 779686-02 (128 MB), and 779686-03 (512 MB). The device has a maximum bandwidth of 60 MHz and a maximum sampling rate of 60 MS per second.
The PCI module can be set up in a PCI peripheral opening or PCI Express hybrid peripheral space. Because some PC cases cause high spectral noise below 5 kHz, the spectrum execution of the National Instruments PCI-5105 oscilloscope is about 5 kHz.
The NI-SCOPE Soft front panel (SFP) allows intuitive control of the PCI-5105. This control of the NI PCI-5105 is most easily achieved in NI-SCOPE SFP fit 14.1. NI-SCOPE SFP is integrated on NI-SCOPE media. The NI Measurement Automation Explorer (MAX) provides an intuitive arrangement and test equipment for the PCI-5105 oscilloscope. MAX is also integrated on NI-SCOPE media. Users can leverage the NI TClk synchronization policy and NI-TCLK driver to adjust the sampling clock on any number of supported gadgets in at least one box. The instrument is equipped with 2 SMB jack front panel connectors.
The NI device weighs 15.2 ounces and measures 14.0 x 0.8 x 4.4 inches. In the physical dimension. It has a recommended operating temperature range of 0 °C to 45 °C, storage temperature range of -40 °C to 71 °C, non-condensing operation and storage humidity range of 10% to 90% RH and 5% to 95% RH, respectively.
Main function
Eight channels were sampled simultaneously
Maximum sampling rate of 125ms /s
14-bit resolution
500mhz real-time bandwidth
Rich trigger function
Large capacity onboard memory * Drives that comply with IVI
use
Testing of electronic equipment
Vibration analysis
Acoustic analysis
Power line analysis
Education and research
