Channel number 16
The maximum sampling rate is 125 ksec/s
12-bit resolution
Real-time bandwidth 500 kilohertz
Memory 256 megabytes
Trigger function edge, level, pulse width, window, etc
Interface PCI interface
Driver IVI guidelines
National Instruments PCI-7811R digital reconfigurable I/O device
The PCI-7811R (Part number: 779363-01) is a digital reconfigurable I/O device from the National Instruments R series. Each module includes a coordinated connector crossover box with screw terminals or link options for adaptable and labor-saving signal wiring. All modules include NI CompactRIO Extreme Industrial certification and rating.
The NI CompactRIO advanced output module connects directly to the RIO FPGA device, creating an elite installation framework that can be fully used for the user's I/ O applications. RIO FPGA devices offer unlimited options for timing, activation, synchronization, advanced waveform generation, or computer communication. For example, the CompactRIO framework can execute a circuit that creates a pulse width regulation (PWM) output for a control engine, heater, or fan, and performs pulse code balanced coding (PCME) for remote telemetry applications.
