PM700WB | Node bus extension cable | Extend the connection distance of the Ethernet network

Package size ‏ : 20 x 12 x 7 inches
First released on shelves ‏ : March 13, 2014
Maker ‏ : Foxboro I/A series
ASIN ‏ : B00J2H720S
The PM700WB node bus extension cable is a device used to extend the bus communication distance and increase the number of bus nodes. The PM700WB can transmit the bus signal over longer distances or distribute the signal to more nodes when the number of bus nodes is large.
PM700WB The following are some common node bus extension cable types:
Ethernet extension cable: Used to extend the connection distance of the Ethernet network, usually using twisted pair or optical fiber as the transmission medium.
USB extension cable: PM700WB is used to extend the connection distance between the USB device and the host, common USB 2.0 and USB 3.0 extension cables.
CAN bus extension cable: As mentioned in Abstract 5, CAN bus Repeaters CAN be used to extend the communication distance of the CAN bus and increase the number of nodes.
When selecting a node bus extension cable, you need to consider the following factors:
Transmission distance: PM700WB determines the transmission distance supported by the extension cable according to actual requirements.
Signal attenuation: the length and material of the extension cord may attenuate the signal, choose the appropriate extension cord to reduce signal loss.
Compatibility: The PM700WB ensures that the extension cable is compatible with the bus protocol and device being used.
Quality and reliability: Select a good quality extension cable to ensure stable communication and a long service life.
