Trusted 40 Channel Analogue or Digital Output
FTA
Product Overview
The Trusted® 40 Channel Analogue Output or Digital Output Field Termination Assembly (FTA) is
designed to act as the main interface between the Trusted Triple Modular Redundant (TMR) 24 Vdc
Digital Output Module T8451, Trusted Triple Modular Redundant (TMR) 24/48 Vdc Digital Output
Module T84611 or Trusted TMR Analogue Output Module T8480 and the field device.
Features:
• 40 output channels per FTA.
• Industry standard field device connections (2-wire).
• Standard DIN rail compatibility.
• Screw clamp terminals on both field and power.
• Simple installation and connection.
• 24 Vdc operation.
• SmartSlot connection for ‘one to many’ hot replacement of output modules.
• Five isolated groups of eight channels.
• On-board LED indication of field power supply.
• Field terminal wire size allowance 12 AWG to 28 AWG
