Dark Horse Safety System /Hima HI quad safety System H41q/H51q series MS/HS/HRS redundant design
H41q/H51q system adopts Qmr quadruple modular CPU structure, that is, the central control unit of the system has four microprocessors, each microprocessor is integrated into a CU module, and the central control unit is composed of two identical CU modules.
The HIQuad system consists of H41q and H51q, which are based on the same hardware and software. They are the third generation of HIMA PES systems that have been proven in production practice. It enables flexible user configuration, monitoring and event logging using a personal computer. Its excellent performance provides the safest control guarantee for production control.
The H41q/H51q system of the Black Horse Security system uses the Qmr quadruple modular CPU structure, which means that the central control unit of the system has four microprocessors, each of which is integrated into a CU module, and the central control unit is composed of two identical CU modules. The CU module forms the 1oo2d structure, and HIMA's 1oo2d structure products comply with AK6/Sil3 safety standards. In order to provide maximum usability to the user, a dual 1oo2d structure, i.e. 2oo4d structure, is used. In the case of redundant architectures, the high-speed dual RAM interface (DPR) enables the two central units to communicate, thus solving the problem of trouble-free maintenance time constraints. Its fault tolerance function makes any component in the system fail without affecting the normal operation of the system.
The H41q Series Dark Horse Safety system is a compact system consisting of a 19-inch rack with a height of five units. The central rack houses all components, including the central unit, interfaces, communication modules, power distribution system, and input and output modules.
Two CU modules and two communication modules
