With the increasing global attention to the development of green energy, the wind power industry ushered in rapid development, China's decentralized wind power resources apart from centralized wind farms began to large-scale access to the grid, in response to this, North China Industrial Control to create a distributed wind power monitoring system real-time data processing and analysis applications such as BIS-6680M
industrial computer products.
Distributed wind power monitoring system is the current research hotspot of smart wind power projects. It is an intelligent system suitable for grid-connected operation, local monitoring and remote management of wind power equipment in various land and Marine environments. It is generally composed of two parts: station control layer and spacing layer. By connecting the field fan master computer platform with the measurement and control device and auxiliary control unit, the real-time acquisition and processing of equipment operation data and the remote data transmission and communication functions with the master computer platform of the station control layer are realized, so as to achieve large-scale access of multiple distributed wind power equipment and intelligent and more efficient remote monitoring and management.
Compared with the
centralized wind power monitoring system, the decentralized wind power monitoring system is more open and universal, but it also emphasizes the data processing ability, network communication ability and operation reliability of the master computer system of the station control layer and the interval layer. Based on this, industrial computer products such as the North China Industrial Control BIS-6680M have become an ideal choice for real-time data processing and analysis of decentralized wind power monitoring systems.
BIS-6680M product performance details
North China Industrial Control BIS-6680M is based on the 10th generation of Intel Core processor, using the company's own
"ice wing" patent cooling structure to create an embedded fanless quasi-system, with excellent computing power, large capacity storage capacity, network communication capabilities, scalability and rugged features, fully meet the needs of distributed wind power monitoring system applications.
BIS-6680M meets the application requirements of distributed wind power monitoring system real-time data acquisition, processing and higher rate network communication:
Support Intel H420E/Q470E/W480E chipset and 10 generation Intel Core i3/i5/i7/i9 LGA1200 processor, with overclocking, multi-thread processing performance; Supports 4GB, 8GB, or 16GB on-board DDR4 memory particles plus 1 x DDR4 UDIMM slots. The UDIMM slots support a maximum of 32GB, and the overall system supports a maximum of 48GB.
Supports 1 x SATA(2.5" hard disk), 1 x M.2 M KEY 2280 (supports NVME/SATA, H420E supports SATA only, Q470E supports NVME PCIEX4) to expand storage capacity.
Support 2*LAN 10/100/1000/2500Mbps RJ45;
Support 4*USB3.0, 4*USB2.0 for multi-computer networking, and 2-10*COM(optional) for higher rates of long/short distance data transmission.
BIS-6680M is equipped with rich functional interfaces, excellent image processing capabilities and scalability to meet the needs of a variety of peripherals for distributed wind power monitoring systems:
Support 1*VGA, 1*DP++, 1*DVI (optional), to meet the independent multi-display and 4K high-resolution display requirements;
Support 1*Mic-in, 1*Line-out audio interface;
Supports 8*GPIO configuration as input, output or multiplexing function;
Support 1*JLPC expansion card for serial port expansion;
Support 1*JPCIE expansion card for expansion network port;
Supports 1*JCOMUSBDDI expansion card Used to expand serial ports, USB ports, and display ports.
With its low power consumption and industrial-grade robustness, BIS-6680M enables safer and more reliable operation of decentralized wind power monitoring systems:
Support Windows 10 (after 1809 version), Linux operating system, and developed the watchdog function, can provide a more stable and easy to use system operation welding;
Adopt fanless "ice wing" heat dissipation structure to provide good heat dissipation performance while reducing power consumption;
Anti-seismic, dust-proof, moisture-proof, can operate stably under various conditions such as
complex electromagnetic environment;
Support DC 12V DC power supply and 0 ° C ~ 60 ° C wide temperature operation;
Small size (280mm x 219.2mm x 88mm), can be mounted on the desktop/wall, easy to deploy.
