5SHY3545L0020 Quasi-system BIS-6670I-B10, suitable for intelligent security gate system control

North China Industrial Control BIS-6670I-B10 is an embedded fanless quasi-system based on the 6/7th-generation Intel Core processor, with powerful data processing capabilities, multimedia performance, scalability and rugged features, fully meeting the needs of intelligent security gate system control products. Security gate as a computer system based control of the channel management equipment, the development has been widely used in airports, subways, railway stations, office buildings, scenic spots and other fields, to assist or replace the manual completion of pedestrian access regulations, charging and ticketing work, help improve pedestrian traffic efficiency and safety, reduce management costs, the industry development prospects are good. With the progress of science and technology and the continuous increase of practical needs, the competition in the security gate market is becoming increasingly fierce, and the intelligent, efficient and personalized products have become the main development trend of the present and future.
01 Development trend of security gate
Intelligent: The security gate has gradually developed intelligent functions such as ID card/passport inspection, face/fingerprint/two-dimensional code recognition, body temperature detection, and data visualization.
High efficiency: The continuous progress of technology has put forward higher requirements for the overall performance of the security gate, such as the use of more advanced computer hardware and automatic control technology, imaging technology and so on to improve the real-time response ability of the equipment, identification accuracy.
Personalized: Users need to carry out differentiated functional development and landing application of security gates based on different fields and realistic needs.
02 Security gate main control hardware requirements
Support AI function deployment: to meet the needs of security gate intelligent recognition technology application, image/video/audio processing, data processing.
Rich I/O functional interface: to support the intelligent security gate face recognition module, communication module, display and other peripheral expansion needs.
Support for personalized customization: Support users to customize the hardware of the main control computer based on the actual application requirements.
Lower power consumption and robustness: The power management and durability of the main control computer hardware directly affect the operation safety and service life of the security gate.
03 BIS-6670I-B10 for intelligent security gates
Based on the 6/7 generation Intel Core processor, the BIS-6670I-B10 embedded fanless quasi system designed by North China Industrial Control for intelligent security gate supports AI function deployment and has the technical advantages of rich functional interfaces, low power consumption, robustness and other technical advantages. The product performance is as follows:
• Support for 6/7 generation Intel Core i3/i5/i7 LGA1151 processors and Intel H110/Q170 chipsets for AI-accelerated computing;
∙ Support 1*SO-DIMM memory slot, supporting DDR4-1866/2133MHz, up to 32GB operating memory;
∙ Support for 1*7+15PIN SATA, 1*M.2 M KEY 2280 (Q170 supports PCIE X4 protocol, H110 supports SATA protocol), and 1*M.2 M KEY 2280 (SATA protocol) to further expand storage capacity;
∙ Support 2*HDMI, 1*DP display interface, can achieve independent multi-display and up to 4K high-resolution display;
∙ Support 1*Headphon, 1*MIC-IN, 1*JAMP audio interfaces to meet the playback needs of a variety of audio devices;
· Support 4* adaptive Gigabit RJ45 network port, support 1*M.2 E-KEY 2230 access WIFI/BT, support 1*M.2 B-KEY 3042/3052 access 4G/5G network module to achieve wired/wireless network communication;
∙ Support 5*USB2.0, 7*USB3.0 interfaces to realize the interconnection of a variety of smart devices;
∙ Support 2*RS232/RS485/RS422, 4*RS232 interfaces to achieve long/short distance and high rate data transmission applications;
∙ Support 1*KBMS, 8*GPIO, 10*DO, 10*DI, 1*SYS_FAN (support speed regulation), 1*JFP, 2*CAN interfaces to achieve more peripheral access;
∙ Passive cooling design to reduce power consumption;
∙ Support DC12V/9~36V single power supply, more stable output;
· Supports Windows 10 and Linux operating systems, and has developed a watchdog function to provide a more open and stable system operating environment;
· Built in strict accordance with industrial standards, to meet the requirements of 0℃ ~ 60℃ wide temperature operation, seismic, dust, moisture, can operate stably in a variety of harsh conditions such as complex electromagnetic environment;
· Size: 236mm*150mm*68mm, small volume, can be mounted on the desktop, wall mount, easier to deploy.
