As a kind of intelligent logistics equipment, AGV robot has developed rapidly in recent years thanks to the development of advanced technologies such as artificial intelligence, the continuous expansion of the scale of domestic logistics and warehousing industry and the continuous promotion of the transformation of digital intelligence in various industries
As a kind of intelligent logistics equipment, AGV robot has developed rapidly in recent years thanks to the development of advanced technologies such as artificial intelligence, the continuous expansion of the scale of domestic logistics and warehousing industry and the continuous promotion of the transformation of digital intelligence in various industries, and has been widely used in logistics and warehousing, manufacturing, medical and other fields. Gradually showing a huge market space and
development potential.However, with the continuous deepening of the application of AGV robots and the progress of technology, the overall performance and quality requirements of AGV robots in the market are also constantly improving. It is necessary to achieve a higher level of iot control, rapid response, motion accuracy, safety and stability to meet the needs of its multi-scene landing applications. Therefore, it is necessary to have data processing ability,
network communication ability, more durable computer hardware to provide it with key support, and North China Industrial Control based on Ruixin Micro RK3568 processor to create an industrial control board EMB-2580, fully meet the needs of AGV robot system control applications.
North China Industrial Control EMB-2580 has the technical advantages of high computing power and large memory, which can help AGV robots achieve more efficient data processing:
∙ Support RK3568 quad-core A55@2GHz processor, integrated 1Tops computing power NPU;
∙ Support 4GB LPDDR4 on-board memory (optional 2-8GB), and support for 1*eMMC (up to 128GB), 1*TF to further expand storage capacity.
North China Industrial Control BIS-6920M meets the product requirements of AGV robot wired/wireless network communication, powerful multimedia
performance and rich expansion:
∙ Support 2*LAN, 10/100/1000Mbps RJ45;
· Support onboard Wifi, Bluetooth, and 1*M.2 interface for 5G network module, and 1*Mini-PCIe slot for 4G/WIFI/MSATA expansion;
∙ Support 1*OTG, 2*USB3.0, 2*USB2.0 to achieve multi-computer networking;
∙ Supports 1*Debug, 1*RS-485, and 2*RS-232 (optional TTL) for higher data transmission rates;
· Support 1*HDMI, 1*LVDS, 1*eDP display output, can achieve the highest 4K resolution display and independent multi-display;
· With 1*Headphone, 1*MIC-IN, 2*5W AMP audio output, to meet the playback needs of a variety of audio devices;
∙ Support 5*GPIO(multiplexing), 2*CAN, 1*I2C, 1*JFP to achieve more peripheral access.
North China Industrial Control EMB-2580 has industrial-grade rugged features, which can enable AGV robots to operate more safely and reliably:
· Support Android and Linux operating systems, and developed a watchdog function to provide a more stable and easy-to-use system environment;
∙ Supports DC 12V single power supply, meets the requirements of wide temperature operation ranging from 0℃ to 60℃, and can operate stably under various conditions such as complex
electromagnetic environment;· Small size (105mm x 80mm), highly integrated and easier to deploy.
Contact Us & North China Industrial Control
As an industry-specific embedded computer product provider, North China Industrial Control has been committed to providing customers with X86 architecture and ARM architecture diversified embedded motherboards, embedded quasi-systems/complete machines and
industrial tablets products and customized services.
