Recently, the Ministry of Industry and Information Technology and other seven departments issued the "Implementation Plan to promote Industrial equipment update", around the promotion of new industrialization, proposed to large-scale equipment update as the starting point, to promote the high-end, intelligent and green development of manufacturing.
Based on this, CNC machine tools, industrial robots, intelligent testing and other intelligent manufacturing equipment, as well as the construction of industrial Internet of things, industrial Internet facilities ushered in new opportunities for development. North China Industrial Control adhere to industrial control empowerment, based on Intel, AMD, SWISchip, NXP, Hisilicon and other platform processors, continuous embedded AI computer innovation output, has successfully created X86 architecture and ARM architecture diversified, specialized, customized embedded AI product solutions for industrial automation applications.
For example, North China Industrial Control based on Intel 12/13 generation Intel Core processor to create embedded AI product solutions - embedded motherboard BPC-7157 and industrial machine BIS-6950P-B10, It has significant advantages in complex computing, large memory, high-speed data transmission, I/O expansion, safer and more reliable operation, and fully meets the application needs of high-end CNC machine tools, industrial robots, intelligent testing and other intelligent manufacturing equipment and industrial Internet facilities.
The BPC-7157 supports Intel H610/Q670E/Z690/Z790 chipset and 12/13th-generation Core i3/i5/i7/i9 LGA1700 processor, TDP up to 125W, up to 24 core 32 threads, and up to 5.8GHz. Intensive AI-accelerated computing that supports parallel multitasking. Supports 2*SO-DIMM dual-channel memory slots, DDR5 4800/5600MT/S, up to 64GB of operating memory, and supports 1*PCIE X1 SLOT expansion 4*SATA3.0 for further expansion of cache and storage capacity.
BPC-7157 is equipped with rich communication interfaces, including 2* gigabit RJ45 network port, 5*USB2.0, 3*USB3.0 and 2*RS232/RS485/RS422 interfaces, supporting 1*M.2 (BKEY 3052/3042 USB3.0 signal 5G module), Meet the product needs of wired/wireless network communication and multi-computer networking. And support 1*HDMI, 1*DP, 1*VGA to achieve independent multi-display and the highest 4K resolution display; Support 1*Mic_in, 1*LINE_OUT, 1*AMP, 1* SPDIFOUT multiple audio interfaces; Supports 1*PCIE 16x slot, 1*PCIE 4x slot, 1*PCIE 1x slot, 1*M.2(MKEY 2280 PCIE X4 signal Q670/Z690/Z790 support) and JEXP high-speed connector for multiple expansions.
BPC-7157 supports Windows 10/11 and Linux operating systems, supports one-click system restore function, hardware call start switch and JCC button, supports TPM2.0, Intel AMT and Intel vPro Technology based on dedicated hardware security enhancement function. It can provide users with a more stable and easy to use system operating environment. It supports 12V DC power supply and meets the operating temperature ranging from 0 ° C to 60 ° C. It is 230mm x 195mm in size and easy to deploy.
BIS-6950P-B10 is an industrial machine independently built by North China Industrial Control based on BPC-7157 embedded motherboard. It supports Intel Q670E/Z690/Z790 chipsets and 12/13th-generation Core i3/i5/i7/i9 LGA1700 processors, which also have high computing power and large memory capacity. However, in terms of the configuration of the I/O functional interface, the BIS-6950P-B10 has been upgraded. It supports 4* gigabit RJ45-POE network port, 6* gigabit RJ45 network port, and 6*RS232/RS485/RS422, 4*USB2.0, 3*USB3.0 interface, can provide a more flexible network application environment.
Supports 1 x PCIe x16(16-lanes) to meet mechanical installation requirements for large graphics cards. PCIE GEN2, 1*PCIE X4 SLOT PCIE X2 signals (or not supported in empty slots) PCIE GEN2, 1*PCIE X4 SLOT PCIE X4 or PCIE X2 signals PCIE GEN2, 1*PCIE X4 SLOT pcie X1 signals GEN3 enables more extended applications. In addition, the BIS-6950P-B10 uses a combination of active and passive heat dissipation design, which can effectively reduce power consumption while ensuring efficient operation of the computer system.
Size 350mm*200mm*230MM(WxDxH), meet 0℃ ~ 60℃ wide temperature working standards, with seismic, anti-electromagnetic interference, moisture and other strong and durable characteristics, suitable for a variety of industrial scenarios.
