At present, the boom of AI large model construction is rushing to intelligent manufacturing, intelligent finance, intelligent medical care, intelligent transportation and other industries, and massive complex needs have prompted computing power to move to the edge.
At present, the boom of AI large model construction is rushing to intelligent manufacturing, intelligent finance, intelligent medical care, intelligent transportation and other industries, and massive complex needs have prompted computing power to move to the edge. In line with the development trend, North China Industrial Control has created an industrial control board EMB-3551 suitable for edge
computing gateway applications.
The market demand for edge computing gateways is high
The edge computing gateway,
in essence, is a device that provides data preprocessing, data analysis, data caching, security protection, network optimization and other services at the edge side near the data source or deployed locally on the device. Compared with the cloud computing mode, it has the technical advantages of lower delay, lower cost, lower power consumption, high security, customization, etc. It is more suitable for large-capacity and complex data processing and analysis tasks, and can also realize the interconnection of a variety of intelligent devices.
With the accelerated development and application of artificial intelligence, 5G, Internet of Things and other technologies, the required computing power is growing rapidly, and the requirements for high bandwidth and low latency of the network are getting higher and higher, and the market demand for edge computing gateways is also rising. In the process of landing the edge computing gateway to the actual scene, complex requirements such as massive data processing, protocol conversion and some harsh environments put forward higher requirements for the data processing capability, customization capability, environmental adaptability and security of key computer hardware, which are often difficult for ordinary commercial computers to meet. With powerful data processing capabilities and rich interfaces, more secure and reliable industrial control computers have become the ideal choice.
Based on this, North China Industrial control to comply with the development trend of The Times and meet the market demand as the guidance launched the industrial control board EMB-3551, not only take into account the performance and power consumption, equipped with rich functional interfaces, but also
achieve high localization rate design, with more safe and reliable and autonomous controllable advantages, fully meet the application needs of edge computing gateway equipment.
Industrial control motherboard EMB-3551 product introduction
North China Industrial Control EMB-3551 industrial control board uses the E2000Q processor, and UOS, Kirin domestic operating system adaptation, with high computing power, large memory, high-speed wired/wireless network communication, multiple expansion, low power consumption, safety and reliability and other performance advantages, can be highly integrated in the edge computing gateway device to achieve multi-scenario application landing.
The main technical characteristics of North China I
ndustrial Control EMB-3551 industrial control board are as follows:
Support Feiteng E2000Q processor, integrate 2 FTC664 and 2 FTC310 processor cores, the highest main frequency of 2.0GHz;
Support PSPA security standard 1.0, support security mechanism based on domain isolation, integrated ROM as a trusted boot root, more secure and reliable;
On-board 4GB DDR4 memory, up to 8GB running memory;
Support 1*SATA3.0 high-speed storage, and 1*TF, 1 M.2 NVMe interface to expand storage capacity;
Support 2*LAN 10/100/1000Mbps RJ45, onboard Wifi, and 1*MINI-PCIE interface to achieve 4G/5G network access to meet wired/wireless network
communication requirements;Support 4*RS-232, 2*RS-232/485 interface to achieve higher rate data transmission, and 2*USB3.0, 4*USB2.0 interface to achieve multi-computer networking;
Support 1*DP, 1* dual channel 24bit LVDS display interface;
Support 1*Headphone, 1*MIC-IN, 2*5W
AMP audio interface;Supports 1* PCIE3.0X4 slot, 2*CAN, 1* buzzer, 1*POWER indicator, and 16 GPIO/SPI/I2C (optional) signals to meet various peripheral access requirements.
Adapted to UOS and Kirin operating systems, the watchdog function has been developed, which can provide customers with a more secure and stable system operating environment;
Passive cooling design, to meet the requirements of 0℃ ~ 60℃ wide temperature operation, and can be power off, clock off, DVFS and nuclear, frequency reduction operation to
reduce power consumption;Built in strict accordance with industrial standards, high reliability, suitable for various harsh environments such as complex electromagnetic environment;
Small size (146mm x 120mm), highly integrated and easy to deploy.
Contact Us & North China Industrial Control
As an industry-specific embedded computer product provider, North China Industrial Control has been committed to providing customers with customized production services for X86 architecture and ARM architecture diversified embedded motherboards, embedded
quasi-systems/complete machines and industrial tablets.
