Technical specifications for IC660MCA512
Brand GE Fanuc
Series Genius I-O
Part number IC660MCA512
Describes the display power adapter
The voltage is 230 volts AC
Equipped with LED PWR, OK, battery
Communication RS 485 series
IP rank
Battery replacement
The GE Fanuc IC660MCA512 adapter module is a power adapter module for GE handheld displays. It is powered by a 230 volt AC supply. It is fully compatible with GE series 90-30 PLC systems. There are 4 leds on the front of the power adapter. When the PWR LED lights up green, it means that all power supplies to and from the adapter are operating normally. If the PWR LED is off, you need to install an external battery and replace the adapter. A green "OK LED" indicates that the CPU is running. A "battery LED" is also included, which should remain off during normal operation. When the Battery LED lights up red, the battery needs to be replaced.
The IC660MCA512 adapter module is equipped with an RS-485 port for communication. Adapter modules are used for handheld monitors that enable operators to monitor I/O and communication status. It supports different languages and is easy to use. The monitor has an LCD and a keyboard. The keyboard has different keys for entering input values and control commands. The LCD screen is bright and can display information related to current input, current output, and fault. The IC660MCA512 adapter module can be connected to a handheld display using a connector port located at the bottom of the display. This port can accommodate a charger and a display adapter. The display uses HHM cables to connect the I/O blocks and other modules in the PLC system. The IC660MCA512 adapter module should be kept away from water and heating devices.
