Technical specifications for IC660MPH509
Brand GE Fanuc
Series Genius I-O
Part number IC660MPH509
Describes handheld display connectors
Connector D housing
Panel mounting support
Color black
Terminal 2
DIN rail mounting support
Objective To install a monitor using a metal bracket
The IC660MPH509 connector is an accessory for handheld displays manufactured by GE Fanuc. It is a display connector kit. The IC660MPH509 connector kit is required when the display needs to be mounted using metal brackets. Each end of the connector kit has a D-shell connector. Each end has a screw for a firm connection. The connector has panel mounting ears for easy panel mounting. Note that panel mounting ears are not required when the display is mounted on a DIN rail. The IC660MPH509 connector kit has two sets of terminals. One terminal is used for the input cable and the other for the output cable. Connector cables use industrial-grade materials to withstand harsh industrial conditions. It's black. During installation, the connector cable should not bend too much near the end of the connector. It should also be kept away from heat.
The GE Fanuc IC660MPH509 Handheld Display Connector Kit is essential for connecting a handheld display to a PLC. These displays are an effective means of allowing operators to connect with GE Genius I/O devices and different networks. These monitors are easy to use and come with a keyboard and LCD screen. The LCD screen is bright and the viewing Angle is good. It supports multiple languages and can display up to 32 characters of information on 2 lines at a time (up to 16 characters per line). The IC660MPH509 connector kit helps connect the monitoring device to the I/O block and other components of the PLC. The display monitor can display information related to the PLC's uptime, diagnostic information, data address, I/O data, and bus scan time. The display is portable and lightweight.
