Technical specifications for IC693ACC300
Brand GE Fanuc
Series Series 90-30
Part number IC693ACC300
Type I/O module
Count 8/16
Power supply DC
Output voltage range 18 to 30 volts DC
Relative humidity 5 to 95% (non-condensing)
15 G at 11 milliseconds of shock
1 G at 9 to 150 Hz
The IC693ACC300 input simulator module is designed for use with programmable logic controllers or PLCS in the 90-30 series, which is manufactured by GE Fanuc. The 90-30 series offers a variety of different industrial components for PLCS for industrial applications that require optimal performance and high reliability. The IC693ACC300 input emulator module is equipped with miniature toggle switches labeled from A1 to A8 and from B1 to B8. These switches have 2 positions, each containing a corresponding green LED that will light up if the corresponding switch is set to "ON". If the corresponding switch is set to "OFF", these leds will turn off. All switches are located at the front of the module. The GE Fanuc input simulator module allows the user to program the switch to operate as a discrete input device, typically used to simulate the operation of the actual input.
When a user needs to develop a PLC or troubleshoot a PLC, the GE Fanuc IC693ACC300 input simulator module can be very important. The device is available with 8 or 16 points or conditional input contacts for manual control of supported output devices. The unit is designed to operate at DC voltage with an output voltage range of 18 to 30 volts DC. The IC693ACC300 input simulator module weighs 0.23 kg (0.5 lb) and has a moderate tolerance for shock and vibration. The relative humidity of the module ranges from 5% to 95% (non-condensing), while its operating temperature ranges from 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit). According to the manufacturer's technical data, the device can be safely stored in a temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit).
