Technical specifications for IC693PRG301
Brand GE Fanuc
Series Series 90-30
Part number IC693PRG301
Describes a handheld programmer
Connector 15 pin D type
Keyboard, yes.
Show yes
Memory card. Yes.
Support for billing list planning
Supported cables Latching Connector cable
Product life cycle status * Discontinued/obsolete
The IC693PRG301 module is a handheld programmer or HHP device manufactured by GE Fanuc. This device is used to configure PLC equipment and I/O parameters. It is a 90-30 series device that can also be connected to a personal computer or CPU using a 15-pin D-connector. HHP is designed to meet the needs of industrial automation applications. The device supports the statement list program. By using the statement list program, the device can edit, insert, and delete program changes. The IC693PRG301 module can be used to monitor the status of reference data or I/O points when viewing logic programs. The HHP comes with a keyboard that can be used to configure and change the operating modes of different PLC devices. There is also an LCD screen and a keyboard that can display information of 2 lines and 16 characters at a time. The content of the screen will depend on the current operating mode and functionality.
The GE Fanuc Series 90-30 IC693PRG301 handheld programmer module communicates directly with the PLC via the RS-422 compatible port. The HHP also comes with a memory card interface that can be used to expand the device's memory. Memory cards can be used to store and retrieve program logic and configuration data. The setup and installation process of the programmer device is simple. The IC693PRG301 handheld programmer module can be connected to the PLC through the device using a cable with a latching connector. The cable is also used to power the device. After connecting the cable, it will indicate to the PLC that the HHP device is connected to it.
