Technical specifications for IC693PWR324
Brand GE Fanuc
Series Series 90-30
Part number IC693PWR324
Description Power supply unit
Voltage 100-240 volts AC
Relay power output 24 volts
Communication RS 485 series
Surge current Max. 4 amps
Maximum power 90 volt-ampere / 50 watts
Field replaceable yes
Product life cycle status * Discontinued/obsolete
The IC693PWR324 module is a power supply unit manufactured by GE Fanuc. It has a load capacity of 30 watts. The nominal voltage input of the power supply unit is 100 to 240 volts AC or 125 volts DC. The power plant is used in the 90-30 GE PLC series. The power supply unit has an automatic range function to adapt to different input power levels. It is also equipped with a current limiting function that can directly turn off the power to avoid further damage to the hardware in the event of a failure. The IC693PWR324 module provides three outputs. It has a 5 volt DC output, a 24 volt DC relay power output to power the circuit, and an isolated 24 volt DC output to provide external power to the input module. The power unit has a detachable terminal board for field wiring connections. It is easy to replace modules in the field without affecting the field wiring.
The GE Fanuc IC693PWR324 power module features advanced diagnostics and a built-in intelligent shutdown system for controller failure events. For communication, the unit is equipped with an RS 485 port. This port can be used to connect to the serial port of a personal computer. The power supply device can be installed in the leftmost slot of the baseplate. The peak surge current of the power module is 4 amps for a maximum of 250 milliseconds. It can absorb up to 90 VA at full load and up to 50 watts at DC input. The IC693PWR324 module should be kept away from the heating device to avoid electrical damage.
