Technical specifications for IC693PWR325
Brand GE Fanuc
Series Series 90-30
Part number IC693PWR325
Description Power supply unit
Voltage 24/48 V DC
Output current 0.8 amps
Peak surge current 4 amps
Battery 1.45 amp hours
Torque is 12 pounds an inch
Standard CE, UL
Product life cycle status * Discontinued/obsolete
The GE Fanuc IC693PWR325 module is an input power device. It has a rated load capacity of 30 watts. It is part of the GE Fanuc PLC and Accessory 90-30 series and is powered by a rated voltage of 24 to 48 volts direct current. The power supply unit provides 5 volts DC output voltage and 24 volts DC relay output voltage to power the circuit. It is also equipped with a 24-volt DC isolated output that powers the input module. The GE Fanuc IC693PWR325 power module has a peak surge current of 4 amps for up to 100 milliseconds. It also has an overvoltage rating of 5 volts DC output. The power unit is easy to configure and install.
The battery module in the IC693PWR325 power unit provides a longer memory backup time than normal batteries. The module supports a compact 1.45 amp hour rated battery. The operating temperature of the battery should be between 0 and 85 degrees Celsius. The power unit can be easily installed on the factory floor or any surface using bolt screws. The power plant is certified to UL and CE standards. The IC693PWR325 module can only be used for indoor applications. It can be connected to a personal computer using a serial port. It's rated at 12 pounds of torque an inch. It has a rated current output of 0.8 amps. The maximum operating temperature of the conductors used in the power supply is 75 degrees Celsius. IC693PWR325 should be kept away from heating devices and electrostatic discharge.
