Technical specification for IC693PWR328
Brand GE Fanuc
Series Series 90-30
Part number IC693PWR328
Description Power supply unit
Input voltage 48 V DC
The output voltage is 24 volts DC
Communication RS 485 series
Compatible with 90-30 series PLCS
Isolation voltage 24 volts DC, 20 watts output
Relay voltage 24 volts DC, 15 watts
Product life cycle status * Discontinued/obsolete
The IC693PWR328 module is a standard power module manufactured by GE Fanuc. It is a 90-30 GE series device that can be used with a 90-30 series PLC. The operating input voltage is 48 volts DC and the output voltage is 24 volts DC. The 90-30 series PLC and accessories such as power supply are the most stable PLCS on the market. The power supply can be used to meet the needs of different PLC applications. The variety and flexibility of the series make industrial automation simple. The module offers advanced communication options through its RS-485 serial port. It can also be connected to a personal computer using a serial port. The IC693PWR328 module is inserted into the leftmost slot of the 90-30 series baseplate. It has three different output capacities, which are 5 volts DC (15 watts output), 24 volts DC isolation voltage (20 watts output) and 24 volts DC relay voltage (15 watts output).
The GE Fanuc Series 90-30 IC693PWR328 power module is equipped with four system status indicators at the top of the front panel. These indicators show the operating status of the power supply, the status of the PLC, whether the RUN mode of the device is being used, and the battery status of the device. The battery compartment is located at the bottom of the device. It is designed to house lithium backup batteries. This battery is connected to the module using the battery connector in the compartment cover. The side panel of the IC693PWR328 module has an internal power supply and AC/DC power connection. The IC693PWR328 module has three output voltages, which are internally connected to the backplane on the backplane. The voltage and power required for these modules is provided through the baseboard connector.
