Technical specifications for IC693TCM302
Brand GE Fanuc
Series Series 90-30
Part number IC693TCM302
Output voltage range 18 to 30 volts DC
External Power 18 to 36 volts DC (2.5 amp surge)
Off state leakage (Max.) 0.1 MA
Load current 100 MA
The internal power used is 150 mA at 5 volts DC
Number of channels 8 inputs / 8 outputs
The overload threshold current is typically 700 MA with a minimum of 2 ms
Thermocouple impedance 30 ohms (Max)
Operating temperature 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit)
Storage temperature -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Product life cycle status * Discontinued/obsolete
The IC693TCM302 module is a temperature control module for GE Fanuc programmable logic controllers or 90-30 series PLCS. Designed and manufactured by GE Fanuc, this high-performance and reliable industrial temperature control module allows users to benefit from the use of 8 input and output channels. The main purpose of the module is to make it easier for users to control and monitor the temperature of their machines and systems. The input channel of the IC693TCM302 module is the thermocouple input channel and its output channel is used for control purposes. The IC693TCM302 module has an output voltage range of 18 to 30 volts DC and a load current of 100 mA. In addition to this, when used with an external power supply, the unit is rated at 18 to 36 volts DC. The unit has an internal power rating of 150 mA at 5 volts DC and a maximum off-state leakage current of 0.1 mA.
The GE Fanuc Series 90-30 IC693TCM302 temperature control module features a typical overload threshold current of 700 mA with a minimum of 2 milliseconds and a maximum thermocouple impedance rating of 30 ohms. This module has an operating temperature range of 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) and a storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The IC693TCM302 temperature control module allows users to choose automatic or manual operation mode according to the requirements of their application. The component also features 12 LED indicators for thermocouple status updates and provides information about faults, such as reverse polarity faults and open circuit faults.
