Technical specifications for IC697BEM764
Brand GE Fanuc
Series 90-70 series
Part number IC697BEM764
This section describes the VME DLAN module
The address options are 16-24-32 bits
Data bus 8-16-32 bits
Temperature 0-60 degrees Celsius
It's 1G at 40 to 150 Hz
Shock 15 G for 11 milliseconds
The voltage is 5/12 volts
Backplane jumper J1, J2
The IC697BEM764 module is a communication module manufactured by GE Fanuc. It is GE series 90-70 PLC communication module. This communication interface module uses the VME or VERSA module Eurocard bus, which helps to connect and connect the module to the microcomputer. VME has 16, 24, and 32-bit address options, and supports 8, 16, or 32-bit data bus options. It has multiple hosts and has a high data transfer rate. The IC697BEM764 module is equipped with slots and racks to easily control DC300 drives, AC2000 drives, and other drives using PLC programs. Be sure to comply with all environmental regulations during installation. The operating temperature should be between 0 and 60 degrees Celsius, and the storage temperature should be between -40 and 85 degrees Celsius. Humidity should be between 5% and 95%, without condensation. It can easily withstand 1 G of vibration at 40 to 150 Hz frequencies, and 11 G shocks at 15 mm seconds.
The GE Fanuc IC697BEM764 PLC communication module operates at 5 and 12 volt bus voltages. The power supply of the module experienced 1 cycle loss without any interruption. If an interrupt occurs, the ACFAIL signal in the module lights up and initiates the close procedure. The module is equipped with 2 backplane jumpers, labeled J1 and J2. The IC697BEM764 communication module is equipped with an 80C186 microprocessor for processing logic operations. In addition, the front panel of the module has an LED status indicator that shows the operating status, data transmission status, and other functional and application data. There is also a restart button in the module for resetting device operations.
