The 140CPS11420 is a PLC module that belongs to Schneider Electric's Modicon Quantum ExosTuxure family of controls. It has the characteristics of high performance, high reliability and easy to use.
The benefits of 140CPS11420 include:
Powerful performance: The 140CPS11420 CPU processing speed is very fast, can meet the needs of most industrial control systems.
High reliability: The module has high reliability and stability, and can operate stably in harsh industrial environments for a long time.
Easy to use: The 140CPS11420 is designed to be simple and easy to use, making programming and maintenance relatively simple.
In addition, the module also has some other characteristics, such as scalability, maintainability, diagnosability, customizability and so on.
Overall, 140CPS11420 is a powerful, reliable and easy to use PLC module suitable for various industrial control fields.
The Schneider Electric 140CPS1 1420 is the subautomation platform in the Modicon power module. It can use additive or standalone power supply types. The module has internal output overvoltage and overload protection
Protect. It comes in a standard module format and weighs 0.65 kg. In a single-position configuration, the 140-CPS-114 20 uses a maximum current of 11 amps. In a totalizable configuration, the maximum current of the module is
20 amps. At full load, phase power consumption is less than 12 watts.
trait
Terminals 1 and 2 of the power patch board have a normally closed relay contact rated for 220 volts AC, 6 amps / 30 volts DC, 5A. The contact group can signal that the input power is off. when
When the input voltage is set to 1 15 volts AC, the relay will be powered off when the input power drops below 70 volts AC. When the input voltage is set to 230 volts AC, the relay will be powered off. It to bus
The output is 5.1 volts DC. No minimum current is required. The input frequency range of the module is 47-63 Hz. The total harmonic distortion of the input voltage of 140CPS1 1420 is less than 10% of the root mean square value of the fundamental wave. Manse
The input power supply is interrupted for less than 1 second within 1/2 cycle of the minimum rated line voltage and frequency.
