Brand: EMERSON
Model: 1C31166G02
Product name: Control motherboard module
Product width: 53 mm
Product height: 125 mm
Product net depth/length: 260 mm
Net weight: 0.7 kg
1C31166G02 is a controller under the Emerson brand, its specific parameters are as follows:
Brand: Emerson.
Model: 1C31166G02.
Controller type: Digital output module.
Applications: Industrial automation, building automation, transportation, etc.
Features: high reliability, wide voltage range, strong anti-interference ability, strong programmability, easy maintenance and so on.
order
Minimum order quantity: 1 piece
Country of Origin: USA
First, the type of analog module
(1) Analog input module
The analog input module, also known as A/D module, converts analog signals collected from various industrial field sensors into digital quantities that the CPU can recognize as received.
(2) Analog output module
The analog output module is also called the D/A module, which is simply to convert the digital quantity sent by the analog input module CPU into other external devices 1 to identify the received voltage or current and other information.
(3) Digital module
The main function of the digital module is to check the status of the external switch input. The digital input/output signal is a switching signal, 1 or 0.
Second, the role of analog module
1. The main function of the analog input module is to collect analog signals. After collecting the external pressure sensor, the analog signal collected by the pressure sensor is collected inside the module and processed accordingly. here
The sensor data includes voltage, current thermal resistance, thermocouple, temperature transition and other analog values, and then transmitted to the intelligent module of the computer through the bus.
2, the role of the analog output module is to convert the input digital signal through the digital-to-analog conversion, and the output can be controlled continuous current and signal.
3, digital module: digital module has two functions: input and output. If this method of integration is not adopted, more space can be saved, otherwise the user needs to buy two modules when using, digital quantity module
The problem is solved, that is, the integrated input/output function, a module can either input signals or output signals.
