Brand: A-B
Model: 61766-17PT
Product type: Industrial monitor
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Product features:The 6176M-17PT is a standard monitor designed as a flat panel industrial color monitor for less demanding environments.
It features a 17-inch display with a resolution of 1280 x 1024 pixels and a display area of 338 x 270 mm (13.3 x 10.7 inches).
A resistive touch screen operating interface allows the user to control the connected machine or process with touch input.
Features USB and RS232 touch screen input, digital video interface, and VGA video input, supporting image rotation, color palette changes, and on-screen display (OSD) for automatic button reset.
Technical specifications:Display: 17-inch flat panel industrial color monitor
Resolution: 1280 x 1024 pixels
Display area: 338 x 270 mm (13.3 x 10.7 in)
Touch screen: resistive
Input interface: USB, RS232, digital video interface, VGA video input
Additional features: Support for image rotation, color palette changes, and automatic button reset
The Allen-Bradley 6176M-17PT monitor is a standard 1750M series industrial monitor. It is a panel-mounted monitor which is directly installed into a panel with mounting clips. The number of mounting clips on the 6176M-17PT monitor is 10. The display is certified by the CE, China RoHS, and European RoHS standards. The display technology used for the 6176M-17PT monitor is color active-matrix TFT LCD. The screen supports a resistive antiglare touchscreen. The touchscreen controller for Series A and B displays is a Panjit controller and for Series C displays, it is an EETI controller. The diagonal display size is 18 inches and the display area is approximately 13.3 x 10.7 inches. The typical display luminance is 300 Nits. The typical contrast ratio is 800:1. The rising response time is 6 milliseconds and the falling response time is 3 milliseconds. The display backlight is rated at 50,000 hours.
The weight of the 6176M-17PT monitor is 12.54 pounds and its dimensions are 14 x 17.8 x 2.1 inches. The display can be. The weight of the 6176m - 17pt monitor is 12.54 pounds and its dimensions are 14 x 17.8 x 2.1 inches used with both AC and DC power. However, a 12 Volts power adapter is required for DC input. The range of AC input voltage in the 6176M-17PT monitor is from 90 to 264 Volts AC. The power consumption rating is 36 Watts (3 Amps). The enclosure of the display is a NEMA type 4, 12 IEC IP 66 enclosure. The operating temperature range is from 0 to 45 degrees Celsius. The storage temperature range is from –20 to 60 degrees Celsius. The operating and non-operating shock ratings are 15 G and 20 G, respectively, for 11 milliseconds. The operating and non-operating vibration ratings are 0.015 inches (1 G peak) and 0.015 inches (2 G peak) peak).
