Brand: MOOG
Model: 761-3033B
Product Type: Flow control servo valve
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Application areas of 761-3033B:Widely used in aviation, aerospace, ships, metallurgy, chemical and other fields of electro-hydraulic servo control system.
In the Chinese market, it mainly serves metallurgy, injection molding, power generation, automobile, machinery manufacturing and other industries.
Product features of 761-3033B:Fail-safe and explosion-proof models are available, including intrinsically safe flame-proof and "safer" designs.
Spool zero notch design, spool valve body/spool sleeve assembly construction, valve functions include Q, P, PQ control.
Parameters such as nozzle size, coil assembly and torque motor operating pressure, valve size and flow rate can be adjusted according to specific requirements.
Technical specifications of 761-3033B:G761 series electro-hydraulic servo valves are high-performance bipolar electro-hydraulic servo valves with rated flow rates of 4L/min to 63L/min at 7Mpa rated pressure drop.
The pilot stage of the valve is a symmetrical double nozzle flapper valve, which is driven by the double air gap of the dry torque motor. The output stage is a four-way slide valve.
The spool position is mechanically fed back by a cantilever spring bar.
