The core components of the TRICONEX 8120E industrial automation control system include the following:
1. Controller: used to receive signals from sensors and send out control signals according to preset control algorithms to control the production process. Common controllers are programmable logic controllers (PLC),
Distributed control system (DCS), etc.
2. Sensors: perceive various physical quantities or states in the production process, such as temperature, excitation, flow, etc., and convert them into electrical signals to transmit to the controller.
3. Actuator: Perform corresponding operations according to the control signal, such as opening or closing the valve, starting or stopping the motor, etc.
4. Human Machine interface (HMI) : In the display and control of automation system, can display real-time production data and equipment status, but also can manually control the system and set parameters.
5. Communication network: Each component and system is connected to achieve data transmission and information sharing, common industrial communication protocols include Ethernet, RS485, Modbus, etc.
6. Fault detection and alarm system: monitoring the operating status of the system and finding faults, timely issuing alarms and notifying maintenance personnel to ensure the safe and stable operation of the system.
7. System integration platform: Liver grid subsystems and modules are integrated together to achieve data interaction and information sharing, and improve the overall efficiency and performance of the system.
These core components together constitute the industrial automation control system, which can realize automated production and management, improve production efficiency and reduce costs.
