Brand: Woodward
Model: 8405-094
Product type: Electric actuators and drives
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
The ProAct Digital Plus is a family of electric actuators with integrated drivers designed to be installed on the engine to control a variety of functions, including (but not limited to) : fuel rack positioning, timing control, and throttle and exhaust bypass valve positioning. The device is actually a locator that will receive the desired position signal from another device in the system, such as speed control, and drive to that location. Each unit includes a digital drive capable of controlling actuators, communicating with external control systems, and contains on-board software and intelligence for monitoring and customization functions.
Woodward's ProAct™ digital electric actuators and positioners include a rotating output shaft for precise positioning of engine control valves.
The ProAct Digital actuator includes an integrated digital driver/positioner for:
Control actuator
Monitor the health of the actuator
Communicate with the control system
Output - Rotation axis, 75 degrees, 7 to 37 J (5 to 27 ft-lb)
Input power - 18-32 Vdc, Max. 20 A
