8516-038 Turbine mechanical hydraulic governor, screw speed set range of 1200-2400 rpm, rated speed down to 2010 rpm, 2°, ATEX position of the drive shaft counterclockwise rotation. The 16 N m (12 ft-lb) counterclockwise rotating output shaft of the governor is connected to the turbine speed-regulating valve to control the turbine inlet steam flow. 8516-038 This independent governor utilizes an integrated driveshaft-driven ball head assembly to detect turbine speed and an integrated driveshaft-driven oil pump to generate the output force needed to move/control the turbine speed-regulating valve.
Replace with: 8516-175 with Overspeed Test Equipment (OTSD), or 9904-814 without OSTD
Applications:
Without the need for synchronous (constant speed) operation, the TG-13 drives the steam turbine in the following positions:
pump
Compressor/turboexpander
Force and intake induced draft fan
dynamo
Features:
Low cost
Speed drop control
Counterclockwise drive shaft
Weatherproof construction
Self-contained sump
NEMA "A" speed control
16 N m (12 ft-lb) output
Designed for harsh environments
HAZLOC and ATEX site certification
