Brand: Woodward
Model: 9908-1501
Product type: Gas control valve
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Woodward's GS16 gas control valve is an electric control valve for on-board drive motors used in industrial gas turbine engines. The gas throttling part of the valve uses a self-cleaning shear action to keep the 1.5 "control port free of contamination, thereby inhibiting optimal performance. The GS16 gas valve is rated at 750 psi and features an electric onboard driver with dual rotary transformers and dual conduit for gas or ambient temperatures up to 200°F (93°C).
9908-1501 product application:9908-1501 Woodward's GS16 gas control valve is a vehicle drive electric control valve primarily used in industrial gas turbine engines.
Technical features of 9908-1501:Self-cleaning design: The gas throttling part of the valve uses a self-cleaning, shearing action to ensure that the 1.5" control port is protected from contamination that could hinder optimal performance.
High performance: The valve is capable of handling gas fuel flows of up to 30,000 lb/h (13,607 kg/h) to meet the needs of industrial and aviation-derived gas turbines.
Temperature adaptability: Valves can be adapted to gas or ambient temperatures up to 200°F (93°C).
Accurate metering: Highly accurate fuel flow metering capability.
Fast response: Full electric actuator and on-board drive guarantee fast dynamic response.
Rugged: The combination of high-torque actuators and rugged self-cleaning valves ensures extended operating time in a variety of gas fuel services.
9908-1501 Interface and signal:Valve assemblies feature on-board electronic controller modules for easy system packaging and installation.
Supports digital and/or 4-20mA analog signal interfaces, providing discrete fault output and independent downtime.
