Alan Bradley 1756-A17 is a Controll ogix component. This is a 17-slot chassis that houses ControlL ogix modules, including processors, I/O modules, professional modules, and coops
Partner module.
The 1756-A17 provides the module housing, including the necessary backplane connections to allow internal module connection and distribution of bus power through embedded electronic circuits, and provides mounting slots for the chassis. Its power consumption is 1.5a
@ 1.2VDC; 4A/ 4a@ 3.3VDC; 15 amp /6 amp hours are 15 amp /6 amp, and 24 volt DC is 2.8 amp /2.8 amp.
The 1756-A17 supports horizontal installation only and requires a minimum cabinet size or available space of 76.2 x 91.4 x 20.3 cm (30 x 36 x 8 inches). The 10 mounting strips provided allow the panel to be mounted directly to the outside
On the panel of the case, the security visit is quick. The case weighs 2.20 kilograms (4.8 pounds).
Combine the 1756-A17 chassis with the nearby ControlLogix chassis - the specific space required for installation is 10.2 cm (4.0 in.) Plus power width (left, 7.7 cm (3.0 in.). Add power
Width (right side), 15.3 cm (6.0 in.) Top clearance and 5.1 cm (2.0 in.) Bottom clearance.
The 1756-A17 was available in three chassis versions, specifically Series A, B, and C. Series C specifically offers improved slot rails, ventilation, stronger mounting pads, additional holes in mounting pads, and ground ends for panels
Connect additional ground screws.
The 1756-A17 standard chassis includes an inherent timestamp function for SOE applications. The chassis backplane distributes power to each module in the chassis by providing a high-speed communication path between modules. Bulletin 1492 required
Wiring IFM or RTB to connect all field side wiring. 1756-A17 standard chassis with RIUP function, pollution maintenance. To prevent replacement errors, it also provides an electronic key. If any system appears
Or field failures, comprehensive diagnostic features help identify failures. It is compact, cost effective, easy to stain and compatible with products such as the PanelView operator.
