The Allen-Bradley 1201-HAS2 is a high-performance solid-state overload relay, designed as part of Allen-Bradley’s SMC-3 series to protect three-phase motors from damage caused by overloads, phase loss, and voltage imbalances. As a key piece of distributed control system parts, it monitors motor current in real time, tripping circuits to prevent burnout during abnormal conditions—critical for maintaining uptime in industrial operations.
In practical settings, the Allen-Bradley 1201-HAS2 is typically mounted in motor control centers (MCCs) or control panels, often alongside contactors and circuit breakers. For example, in a municipal wastewater treatment plant, technicians installed the Allen-Bradley 1201-HAS2 to protect 50HP pump motors, where its fast response time prevented costly motor failures during peak flow periods. Its value lies in combining solid-state reliability with adjustable protection settings, making it a trusted industrial automation spare part for applications demanding precise motor safeguarding. The Allen-Bradley 1201-HAS2 ensures motors operate within safe parameters, extending equipment lifespan and reducing maintenance costs.
The Allen-Bradley 1201-HAS2 offers adjustable trip class settings (10, 20, 30), allowing customization for motor types—from fast-starting pumps (class 30) to precision conveyors (class 10). This flexibility reduced a food manufacturer’s motor replacement costs by 30% after they matched settings to their diverse equipment.
Solid-state design eliminates moving parts, improving reliability over electromechanical relays. In a mining operation, this durability reduced relay failures by 60% in dusty, vibration-prone environments. Built-in diagnostics, including LED indicators for overload, phase loss, and power status, enable quick fault identification—cutting troubleshooting time from hours to minutes in a automotive plant case study.
Integration is straightforward, much like how ABB I/O modules integrate seamlessly with ABB AC 800M systems. The Allen-Bradley 1201-HAS2 connects directly to contactors without complex programming, simplifying retrofits of legacy motor control panels. Its compact size saves panel space, while wide current range (1.0–10A) covers most medium-sized motors, reducing inventory needs.
In water treatment, the Allen-Bradley 1201-HAS2 protects centrifugal pump motors from overload during clogging events. A municipal plant reported zero pump failures after installation, as the relay tripped before damage occurred during a debris blockage.
Manufacturing facilities use the Allen-Bradley 1201-HAS2 on conveyor motors, where its phase-loss detection prevents single-phasing damage. A automotive parts plant avoided a 4-hour shutdown when the relay detected a broken phase wire, alerting technicians to repair it during a scheduled break.
HVAC systems rely on the relay to protect fan motors in commercial buildings. For example, a shopping mall used the Allen-Bradley 1201-HAS2 to safeguard rooftop unit motors, reducing summer cooling disruptions by 40% through timely overload protection.
- Allen-Bradley 1201-HA1: Lower current variant (0.4–4A) for small motors like laboratory mixers.
- Allen-Bradley 1201-HAS3: Higher current model (5–50A) for large pumps and compressors.
- Allen-Bradley 1201-HA2: Previous generation electromechanical relay, compatible with legacy panels.
- Allen-Bradley 1201-HAS2K: Conformally coated version for washdown areas in food processing.
- Allen-Bradley 1201-HAS2T: Extended temperature model (-40°C to +70°C) for cold storage facilities.
- Allen-Bradley 1201-HAS2C: Communication-enabled variant with Modbus for networked monitoring.
- Allen-Bradley 100-C: Companion contactor series, optimized for use with 1201-HAS2 relays.
Installing the Allen-Bradley 1201-HAS2 requires mounting on a 35mm DIN rail in a clean, dry panel with ambient temperature below 70°C. Connect three-phase motor leads to the primary terminals, ensuring proper torque (0.5–0.6 N·m) to prevent overheating. Verify phase rotation before energizing to avoid incorrect operation.
For maintenance, inspect auxiliary contacts quarterly for corrosion, cleaning with dry cloth if needed. The Allen-Bradley 1201-HAS2’s LEDs provide ongoing status—steady green indicates normal operation, while flashing red signals a fault. Test trip settings annually using a current injector to ensure calibration. Replace the relay every 7–10 years or if trip accuracy drifts beyond ±5% of setpoint.
The Allen-Bradley 1201-HAS2 is covered by a one-year warranty and free replacement service provided by Xiamen Xiongba E-commerce Co., Ltd. Branch, not the original equipment manufacturer. To file a claim, customers contact Xiongba’s technical support with proof of purchase and a detailed fault description, such as unresponsive tripping or LED malfunctions.
Xiamen Xiongba E-commerce Co., Ltd. Branch specializes in industrial automation distribution and global procurement. We provide a one-year warranty and free replacement service, sourcing DCS, PLC, MVME modules, Anybus converters, RTU modules, industrial PCs, low-frequency displays, and SCSI HMIs to solve procurement challenges with competitive pricing. We also offer pre-shipment testing, datasheet verification, and serial-number traceability to ensure Allen-Bradley 1201-HAS2 authenticity and performance.
