The Allen-Bradley A-B 1336-WB110 is a critical accessory in the 1336 series of adjustable frequency drives, engineered to address harmonic distortion—a common challenge in industrial automation systems. As a waveform filter, its core function is to smooth voltage and current waveforms from the drive to the motor, reducing electrical noise and harmonic interference that can degrade equipment performance.
In automation setups, the A-B 1336-WB110 acts as a protective bridge between the drive and motor, ensuring clean power transmission that extends component lifespans and reduces unplanned downtime. Its compact design makes it ideal for integration in control cabinets, where space is often at a premium. For example, in an automotive assembly plant, engineers frequently mount the A-B 1336-WB110 alongside 1336 drives in motor control centers, ensuring reliable operation of conveyor systems and robotic arms. This focus on practical integration solidifies the A-B 1336-WB110 as a trusted component in distributed control system parts inventories.
The A-B 1336-WB110 delivers tangible advantages through its engineering focus on reliability and integration. Its low-loss ferrite core design reduces harmonic distortion by up to 30% compared to unfiltered drive outputs, protecting motors from overheating and insulation breakdown—a critical benefit in 24/7 industrial environments.
Durability is another strength: the A-B 1336-WB110 features a rugged metal housing that shields internal components from mechanical stress and electrical interference, ensuring consistent performance even in vibration-prone settings like mining operations.
Integration is streamlined, too. Unlike bulkier alternatives, its compact footprint fits seamlessly in existing control cabinets, minimizing retrofitting time. The A-B 1336-WB110 pairs naturally with Allen-Bradley’s 1336 drive series and works with common industrial automation spare parts, making it a versatile choice for both greenfield installations and brownfield upgrades. For engineers, this means fewer compatibility headaches when integrating with DCS architectures, including setups using ABB I/O modules or ABB AC 800M systems.
The A-B 1336-WB110 excels across diverse industrial sectors where drive reliability directly impacts productivity. In water treatment plants, it ensures consistent power delivery to pump motors, reducing nuisance trips caused by harmonic interference—critical for maintaining water pressure in municipal systems.
In discrete manufacturing, such as electronics assembly, the A-B 1336-WB110 protects precision motors in conveyor and pick-and-place equipment, minimizing downtime from unexpected failures. A recent retrofit at a beverage bottling plant illustrates this: technicians replaced outdated filters with A-B 1336-WB110 units, cutting motor maintenance calls by 40% within three months.
Mining operations also benefit, as the filter’s robust design withstands the dusty, high-vibration environments of ore processing facilities. Here, the A-B 1336-WB110 ensures drives powering crushers and conveyors operate efficiently, even when grid voltage fluctuates.
- 1336-WB100: Lower-power variant (5A) for smaller 1336 drive systems.
- 1336-WB200: Higher-voltage option (480V) for industrial heavy-duty applications.
- 1336-RF100: Companion reactor for enhanced harmonic mitigation when paired with A-B 1336-WB110.
- 1336-ENET: Ethernet communication module for remote monitoring of 1336 drive systems.
- 1336-GM100: Grounding module to complement A-B 1336-WB110 in noise-sensitive setups.
- 1336-PB100: Power bypass module for uninterrupted operation during drive maintenance.
- 1336-HMI100: Local operator interface for configuring drives paired with A-B 1336-WB110.
- 1336-DRV100: Base 1336 adjustable frequency drive, the primary companion to A-B 1336-WB110.
Installing the A-B 1336-WB110 requires adherence to basic industrial standards. Mount the unit on a 35mm DIN rail in a control cabinet with at least 50mm of clearance above and below for ventilation—critical for preventing overheating in enclosed spaces. Ensure proper grounding via the dedicated terminal to minimize noise transfer to other components.
For maintenance, conduct quarterly visual inspections to check for loose connections or dust buildup; compressed air can safely remove debris. The A-B 1336-WB110 has no user-serviceable internal parts, so rely on drive event logs to monitor performance trends. If harmonic distortion levels rise unexpectedly, verify wiring integrity before considering replacement. Xiamen Xiongba E-commerce Co., Ltd. Branch recommends firmware backups for paired drives to simplify troubleshooting.
The A-B 1336-WB110 comes with a one-year warranty and free replacement service provided exclusively by Xiamen Xiongba E-commerce Co., Ltd. Branch, not the original equipment manufacturer. Customers can initiate claims via email or phone, providing serial numbers and purchase details for verification. Xiamen Xiongba also offers pre-shipment testing, datasheet verification, and full serial-number traceability to ensure product authenticity. This support network ensures peace of mind for industrial buyers relying on the A-B 1336-WB110 in critical applications.
Xiamen Xiongba E-commerce Co., Ltd. Branch specializes in industrial automation distribution and global procurement. We provide a one-year warranty and free replacement service, sourcing DCS, PLC, MVME modules, Anybus converters, RTU modules, industrial PCs, low-frequency displays, and SCSI HMIs to solve procurement challenges with competitive pricing.
