The ModBus Garden and Rack interface modules are designed to provide high reliability for the plant's most critical rotating machinery. It reads the parameters from all AMS 6500 modules and outputs them via ModBuS TCPIP and/or ModBuS RTU(serial). The 1-socket monitor can be used with other AMS 6500 monitors to form a complete API670 mechanical protection monitor. Applications include steam, gas, compressors and hydraulic turbomachinery.
Operator access to mechanical health parameters in the control environment for seamless integration. This module powers the local graphic display on the protection rack for reading machine and instrument information. ModBus TCP network /P or ModBus RTU can be configured, or both redundant paths can be used.
specification
3U size, 1 slot plug-in module, compared with the traditional 6U card, the cabinet space requirement is reduced by half
Compliant with API670, hot-swappable modules
Password protected user configuration
The self-test function includes monitoring hardware, power input, and hardware temperature
