Digital Model :5SHY4045L0006 Manufacturer :ABB
Weight :1Kg Shipping weight :2Kg
Quantity :2
Warranty :1 year Import: Yes sales: nationwide
Shipping time :DHL/FEDEX /EMS/UPS/TNT/EMS
Product features:
Plug and play
Program debugging
Technical installation
ABB 5SHY4045L0006 3BHBO30310RO001 IGCT series module
IGCT Intergrated Gate Commutated Thyristors (IGCT integrated gate commutated thyristors = gate commutated thyristors + gate units) is a type of power semiconductor switching device developed by a medium voltage inverter for use in large power electronics packages.
|
Label
|
Specification
|
|
Model Number
|
6ES7315-2AG10-0AB0
|
|
Brand
|
Siemens
|
|
Type
|
CPU Module (S7-300 Series)
|
|
Input Voltage
|
24V DC (±10%)
|
|
Operating Temp
|
0°C to 60°C (32°F to 140°F)
|
|
Communication Method
|
Profibus DP, MPI
|
|
Mounting
|
DIN Rail (35mm)
|
|
Weight
|
0.38 kg (0.84 lbs)
|
|
Certifications
|
CE, UL, CSA, ATEX
|
|
Dimensions
|
125mm × 80mm × 62.5mm (H×W×D)
|
|
IP Rating
|
IP20 (Protected against solid objects ≥12mm)
|
|
Protocols Supported
|
Profibus DP V1, MPI, PPI
|
|
Memory
|
256KB Work Memory (128KB Code / 128KB Data)
|
|
Expansion Slots
|
4 (for S7-300 I/O Modules)
|
It was proposed by ABB in 1997. IGCT has made great progress in power, reliability, switching speed, efficiency, cost, weight and volume, and has brought a new leap to power electronic complete sets.
Product Overview:
IGCT integrates the GTO chip with the anti-parallel diode and gate driver circuit, and then connects it with the gate driver in a low inductance mode at the periphery, combining the stable turn-off ability of the transistor and the advantages of the low on-state loss of the thyristor.
The performance of thyristor is displayed in the on-stage, and the characteristics of transistor are displayed in the off-stage. IGCT has the characteristics of large current, high blocking voltage, high switching frequency, high reliability, compact structure, low on-off loss and so on, and has a good application prospect.
