Number: 3HAC058038-001
General information
Product Number: Number: 3HAC058038-001
dimension
Net weight: 0.2kg
Gross weight: 0.2 kg
Net depth/length: 118mm
Product height: 94 mm
Product width: 40mm
ABB model name: -
Catalog Description: DSQC1023 RS box WiFi
DSQC1032 module plays the role of Ethernet/IP bus adapter (slave station module),
The DSQC1032 communicates with the host through network cables.
ABB robot input and output module gradually uses ABB DSQC1032 to relocate the original DSQC652 module.
ABB DSQC1032 is based on the Ethernet/IP protocol. When using this module, the robot does not
The DSQC1032 module acts as an Ethernet /IP bus adapter (slave module), DSQC1032
Communicates with the host through network cables.
If you want to add DSQC1031 (16DI 16DO) or DSQC1032 (4AI4AO) later, you must use it with DSQC1032.
The DSQC1032+DSQC1032 combination must be used, and DSQC1032 cannot be used alone.
In the preceding figure, configure DSQC1032+DSQC1032.
