1753-L32BBM-8A AB controller
Allen-Bradley 1753-L32BBM-8A is the GuardPLC 1800 series safety controller. This controller has the most I/0 points among GuardPLC controllers. It is equipped with 32 I/O points (24 inputs)
And 8 outputs, none of which are electrically isolated). Output channels 4 and 8 can withstand 1 amp current at 60 degrees Celsius and other channels are rated at 0.5 amp. The 1753-L32BBM-8A controller also has two 24-bits
High speed counter with resolution (non-electrically isolated). 250kb of user program memory and 250kb of application data memory were installed to support microprocessor troubleshooting. The device will detect the behavior of its control system
And put all affected inputs and outputs of the failed module into a safe state.
A special feature of the 1753-L32BBM-8A GuardPLC 1800 controller is the Modbus communication option. Users can use this communication protocol to exchange signal values and other data with other industrial automation equipment. Mr.
The Ren-Bradley 1753-L32BBBM 8A is designed to connect to a 24 volt DC/8 amp power supply. It has an IP20 protective housing, measuring 114 mm (4 49 in)x 257 mm (10.1 in)x 80 mm (3.15 in)
Inch), including shielding plate. It weighs about 2.6 pounds (1.2 kg). Do not use this device outside the temperature range of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). The controller has passed rigorous testing and passed
CE,C-Tick and c-UL-us standard certification.
