The 1762-0W16 is a MicroLogix relay output expansion module. The module is used to enhance the output capabilities of the MicroL ogix 1100, 1200 and 1400 programmable logic controllers (PLCS). It is compatible for electrical loads
Power on and power off.
The module has sixteen (16) relay contact outputs and operates in the 24-125VDC and 120-240 VAC voltage ranges. For ON-to-OFF and off-to-on conversions, the signal delay time for each output channel is 10
ms. The continuous current rating of each point of the module is 2.5A, the continuous current of each common end is 8A, and the continuous current of each module is 16A. The 1762-0W16 has two (2) output groups, each consisting of eight (8) channel groups
Agreed. Group 0 consists of outputs 0-7, while group 1 consists of outputs 8-15.
It is recommended to install the surge suppressor on the inductive load. This surge suppressor provides protection against the high surge current of inductive loads, thereby helping to extend the service life of the module.
When used with the MixroLogix 1100 controller, up to four (4) instances of this module can be installed. If used with MicroL ogix 1200, up to six (6) modules are supported compared to MicroL ogix 7
Seven (1500) modules are allowed when used together.
The physical dimensions of the module are 90x 40.4x87 meters (3.54x 1.59x3.43 inches) and the height is 110 meters (4.33 inches) including the mounting strip. Installation depends on the base controller. As Microl ogix 1100 1
Standard with 1200 and 1400 controllers, the module supports DIN rails with direct panel mounting.
The Allen-Bradley 1762-0W16 module is a relay output module that can operate on both DC and AC power supplies. Its design. The operating voltage range is 5 to 265 volts AC and 5 to 125 volts DC. 1762 -
The OW16 has 16 outputs, a maximum heat dissipation of 6.1 watts, and a housing type rating of IP20. The module weighs about 0.63 pounds. The maximum bus current consumption of the module is 5mA at 140 volts DC and 180 volts DC
The pressure is 24 mA. The minimum conduction current of the 1762-0W16 is 10 mA. The maximum continuous current at each point is 2.5A, the maximum continuous current at common points is 8A, and the maximum continuous current at each module is 16A. 1762-0W16 Max
The controlled load is 1440 VA.
The 1762-0W16 module has 4 relay contact ratings. The rated voltages of the relay output are 24 volts DC, 125 volts DC, 120 volts AC, and 240 volts AC. For 240 to 120 volts AC, per point
The maximum continuous current is 2.5 amps. For 125 volts and 24 volts DC, the maximum continuous current at each point is 2 amps and 1 amp. Connecting a surge suppressor device to an external inductive load will extend the service life of relay contacts
Life. For more details, see Allen-Bradley's wiring guide. Keep in mind that electrostatic discharge can damage the 1762-0W16's semiconductors.
