The 2711-K5A2 is a touch screen product from Rockwell Automation that features 170KB of internal random access memory (RAM) and 240KB of non-volatile memory to hold applications and system files. The device also features a 5.5-inch monochrome LCD blue mode screen that can be configured using the PanelBuilder 32 software. In addition, the 2711-K5A2 has an embedded DH-485 communication port to interact with other machines.
The 2711-K5A2 can be installed in NEMA or IP rated housing, providing adequate protection against water, dust, dirt, corrosion and explosive substances. It can also be installed in NEMA type 12/13, 4X (indoor use only), IP54 and IP65 or any equivalent grade housing.
The 2711-K5A2 is an Allen-Bradley PanelView Standard operating terminal with an integrated keyboard input interface, display area, communication port, and internal memory. The electronics feature compact components that support flush mounting onto an industrial-grade housing.
The 2711-K5A2 keyboard input interface consists of ten (10) function keys that accept local and global assignments, making any button available for a specific function or accepting variable assignments. In addition to function keys, the keyboard component also has a numeric key for entering numeric variables and constants; Navigation key, used to highlight the corresponding object displayed on the screen.
The operating terminal also features a 5.5-inch monochrome screen with a display area of 120 x 60 mm (4.75 x 2.38 inches) and a resolution of 256 x 128 pixels. It comes with a replaceable internal backlight and is designed to operate for up to 100,000 hours.
This shortens and maximizes engineering time, as internal testing can also be done without the need for physical hardware.
The 2711-K5A2 has a 170KB internal random access memory (RAM) and a 240KB non-volatile memory for holding application and system files such as trends, logs, and user manuals.
The 2711-K5A2 is mounted on a NEMA or IP grade housing and provides adequate protection against water, dust, dirt, corrosive and explosive substances. Install the 2711-K5A2 in NEMA Type 12/13, 4X (indoor use only), IP54 and IP65 or any equivalent rated housing.
The 2711-K5A2 is an Allen-Bradley PanelView 550 terminal. This outdated operating terminal allows users to connect to other machines. This PanelView device is 5.5 inches. Monochrome LCD blue mode screen. It has an embedded DH-485 communication port. Users can control the device using an embedded keyboard located on the front panel of the device.
Its DH-485 communication port can be connected to SLC and MicroLogix controllers, DH-485 networks, or wall-mounted power supplies. The 2711-K5A2 terminal uses a 120 volt AC power supply. The unit has 170 KB of application runtime memory and 240 KB of non-volatile memory. The internal backlight replacement part number of this unit is 2711-NL1. The approximate shipping weight and dimensions of the terminal are 6 pounds and 14 x 11 x 8 inches, respectively.
