The AN-X2-AB-DHRIO is a communication module manufactured by Alan Bradley partner company Prosoft Technology. This communication device is compact and can be mounted on a desktop or DIN rail
Pretend. It allows modern programmable automation controllers (PACs) such as Allen-Bradley's ControlLogix and CompactLogix controllers to work with traditional remote I/0 (RIO) and Data Highway
The Plus (DH+) communication protocol is used to communicate with devices.
The AN-X2-AB-DHRIO is equipped with one (1) Ethernet /P communication interface that supports 10/100 mbps data transfer rates.
This port connects the PAC end C] to the gateway, an X2 a B-DHRIO is available
The 3-pin Phoenix Network connector allows Daisy chain connectivity of devices such as Allen-Bradley's PLC, SLC 500, PanelView, drives and Flex /O adapter modules. The communication interface supports
Configurable data transfer rates, including 57.6, 115.2 and 230.4K baud. It also comes with another 3-pin Phoenix connector that hooves to an external 24-volt DC power supply.
AN-X2-AB-DHRIO also has a built-in network server that allows for remote monitoring and configuration of the gateway. Other supported operations that can be started through the web server include diagnostic data display, configuration, and upload configuration
File and operation mode Settings. This can be done with a standard web browser.
The AN-X2-AB-DHRIO is ideal for integration into modern control systems for legacy equipment, as well as cost-efficient porting of mature and obsolete products. It allows the continued use of these devices without the need to be complete
Replacement provides customers with a flexible and practical alternative solution to their existing automation requirements.
AN-X2-AB-DHRIO module Alan Bradley Ethernet /IP to DH+ or RIO network connector. This communication module of the Control ogix series helps to Control ogix PLC or others
Compatible devices connect to the Allen-Bradley remote I/O network. Communication module with 1 I/0 channel. Supports all remote I/O baud rates from 57.6 to 230.4 kilobd. The module supports from 0 to 76
Octal frame number. The utility maps remote I/O data to Control ogix schedule data. The module is connected to the C ontroll ogix processor by using a scheduled connection over Ethernet. Communication mode
There are two LED indicators on the front of the block, which are used to show the Ethernet connection status, and another LED indicator is used to show the internal communication status of the module.
The operating temperature of the Allen-Bradley Ann X2-AB-DHRIO Controll ogix communication module should be set between 0 and 50 degrees Celsius. Can be easily installed using DIN rail. Ann X2 AB DHRIO mold
The blocks are rated for power consumption of 200 amps with a rated voltage of 12 volt DC or 100 amps with a rated voltage of 24 volt DC. The maximum power consumption rating of the communication module is 2.4 watts. The Ann X2 AB DHRIO module helps
To replace the existing remote I/O PLC. It helps build new controller programs without disrupting existing control systems and minimizes downtime. It comes with an auto-configuration utility
Program that can discover the baud rate and map discrete I/O to reduce configuration errors. The communication module is equipped with an RJ 45 10/100 Mbpsl Ethernet port, a phoenix 3-pin power connector, and one
Phoenix 3-pin network connector.
