Product Overview
The BENTLY 132417-01 is a robust termination module designed for seamless integration with Bently Nevada’s 3500 Machinery Protection System, serving as the critical interface between field sensors and the system’s monitoring modules. This module simplifies the complex wiring of industrial sensors—such as vibration probes, temperature transducers, and position detectors—by providing organized terminal connections that streamline signal routing to components like the 3500/53 vibration monitor.
In automation setups, the BENTLY 132417-01 eliminates the chaos of loose wiring, reducing the risk of signal interference or connection failures that can compromise machinery monitoring. Its design ensures that sensor signals reach processing modules intact, even in high-vibration environments like near turbine enclosures. What makes the BENTLY 132417-01 valuable is its ability to scale with system expansion: additional sensors can be integrated without rewiring the entire rack, making it a flexible solution for growing industrial facilities. Whether in new installations or retrofits, this module is indispensable for maintaining reliable, organized connectivity in critical machinery protection systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
BENTLY 132417-01 |
| Manufacturer |
Bently Nevada |
| Product Type |
Terminal Connection Module (3500 Series) |
| Terminal Count |
32 screw terminals (16 input, 16 output) |
| Wire Gauge Compatibility |
22-14 AWG (0.32-2.08 mm²) |
| Operating Voltage |
Passive (no external power required) |
| Operating Temperature |
-30°C to 70°C (-22°F to 158°F) |
| Dimensions |
102mm x 165mm x 52mm (4.0" x 6.5" x 2.0") |
| Mounting Type |
3500 series rack slot mounting |
| Material |
Glass-reinforced polyester (housing), nickel-plated brass terminals |
| Compatibility |
3500/53, 3500/64M, 125704-01 modules |
| Certifications |
UL 508, ATEX, IECEx |
| Weight |
0.7 kg (1.5 lbs) |
Key Features and Benefits
The BENTLY 132417-01 excels in simplifying sensor integration, with 32 clearly labeled terminals that reduce wiring errors during installation—a common source of downtime in industrial setups. Its modular design allows technicians to add or replace sensors without disrupting the entire system, saving hours of maintenance time compared to hardwired configurations.
Constructed from durable glass-reinforced polyester, the BENTLY 132417-01 withstands harsh industrial conditions, including exposure to oils, coolants, and high vibration—critical for reliability in environments like offshore platforms or steel mills. The nickel-plated brass terminals resist corrosion, ensuring stable signal transmission over years of operation, even in humid or salty atmospheres.
The module’s passive design (no external power needed) eliminates the risk of power-related failures, making it a low-maintenance component in the 3500 system. Its compatibility with a wide range of 3500 modules ensures it fits seamlessly into both new installations and legacy systems, preserving existing infrastructure investments while enhancing wiring efficiency.
Application Scenarios
The BENTLY 132417-01 is a workhorse in industries where organized sensor wiring is vital to machinery protection. In coal-fired power plants, it terminates wiring from eddy current probes monitoring turbine shaft vibration, routing signals cleanly to 3500/53 modules—preventing signal loss that could mask early signs of rotor imbalance.
In oil refineries, the BENTLY 132417-01 simplifies connections for temperature sensors on catalytic cracker pumps, organizing dozens of wires into a single module to reduce clutter in control cabinets. This organization is critical during emergency maintenance, allowing technicians to quickly identify and troubleshoot sensor issues.
Within chemical processing facilities, the module connects pressure transducers on reactor agitators to 3500 monitoring systems, with its corrosion-resistant terminals ensuring reliable signal transmission even amid chemical fumes. Its rugged design also makes it ideal for mining operations, where dust and vibration can degrade unprotected wiring connections.
Related Models
132417-02 – High-density variant with 48 terminals, designed for large-scale sensor networks.
132416-01 – Previous generation termination module with basic terminal labeling, compatible with older 3500 racks.
3500/53 133396-01 – Vibration monitoring module that receives signals routed through BENTLY 132417-01.
125704-01 – Rack interface module that works with BENTLY 132417-01 to coordinate signal flow in the 3500 system.
132417-03 – Explosion-proof version with sealed terminals, suitable for Zone 1 hazardous areas like paint booths.
3500/64M 140734-05 – Relay module whose alarm wiring is often terminated via BENTLY 132417-01.
Installation and Maintenance
Installing the BENTLY 132417-01 requires a vacant slot in the 3500 series rack, with at least 30mm of clearance above and below to facilitate wiring access. Ensure the rack is properly grounded to minimize electrical interference, and verify that terminal labels align with sensor types (e.g., vibration, temperature) to avoid cross-wiring. Use torque tools to secure wires to terminals (recommended 0.5-0.7 Nm) to prevent loose connections.
For maintenance, inspect the
BENTLY 132417-01 quarterly, checking terminals for corrosion or loose wires. Clean terminals with a dry cloth to remove dust or debris that could impede signal flow. Re-torque connections annually to maintain proper contact, especially in high-vibration environments. Replace the module if terminals show signs of excessive wear or housing damage to ensure uninterrupted signal transmission.
Product Warranty
The BENTLY 132417-01 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials and workmanship. During this period, we provide free replacement for any module that fails under normal operating conditions, ensuring minimal disruption to your 3500 system. Our technical support team offers guidance on installation and wiring best practices, leveraging deep experience with Bently Nevada termination products. We stand behind the reliability of the BENTLY 132417-01, ensuring it meets the rigorous demands of industrial sensor connectivity.
