Product Overview
The 132419-01 is a precision sensor termination module from Bently Nevada, designed to serve as a critical connection hub in machinery protection systems. As a key accessory in Bently’s 3500 and 3300 series ecosystems, its primary function is to organize and secure wiring between field sensors—such as proximity probes, accelerometers, and RTDs—and monitoring modules like the 3500/33 vibration monitor or 3500/42M temperature module. This centralized termination simplifies installation, reduces wiring errors, and preserves signal integrity, making it indispensable in industrial setups where accurate data from rotating equipment (turbines, compressors, pumps) is vital for early fault detection.
What sets the 132419-01 apart is its rugged design and seamless integration with Bently’s sensor portfolio. It accommodates multiple sensor types, from 3301 proximity probes to 3500-series seismic sensors, with dedicated terminals that minimize electromagnetic interference (EMI). Its robust construction withstands extreme temperatures, vibration, and chemical exposure, ensuring reliable performance in harsh environments like power plant turbine rooms or offshore oil platforms. By streamlining sensor-to-module connections, the 132419-01 enhances system reliability, reduces downtime, and supports proactive maintenance strategies—key for industries where equipment failure risks safety and productivity.
Technical Specifications
| Parameter |
Value |
| Product Model |
132419-01 |
| Manufacturer |
Bently Nevada |
| Product Type |
Sensor Termination Module (3500/3300 Series Accessory) |
| Input Compatibility |
Proximity probes, accelerometers, RTDs, thermocouples |
| Number of Channels |
8 configurable input channels |
| Terminal Type |
Screw terminals with strain relief |
| Housing Material |
Anodized aluminum |
| Operating Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Mounting Type |
DIN rail or panel mount |
| Certifications |
UL, CE, ATEX |
| EMI/RFI Protection |
Integrated shielding and twisted-pair terminals |
| Compatibility |
3500/33, 3500/42M, 3300/20 modules; 330103 probes |
| Dimensions |
120 mm × 80 mm × 60 mm (W×H×D) |
Key Features and Benefits
The 132419-01 excels in simplifying sensor integration, a common pain point in complex machinery monitoring systems. With 8 configurable channels, it accommodates a mix of sensor types—eliminating the need for multiple specialized termination blocks. This versatility reduces inventory costs and streamlines installation, particularly in retrofits where legacy and modern sensors coexist.
Signal integrity is a defining strength. Integrated shielding and twisted-pair terminals minimize EMI/RFI interference, ensuring that weak signals from proximity probes (measuring micrometer-level vibrations) remain accurate. This is critical in environments like steel mills, where heavy machinery generates significant electrical noise that could corrupt data.
Ruggedness ensures durability. The anodized aluminum housing resists corrosion from oils, chemicals, and salt spray, making the 132419-01 suitable for offshore platforms and chemical plants. Its wide operating temperature range (-40°C to 70°C) allows deployment in unheated enclosures or hot industrial zones, such as turbine rooms.
Ease of use enhances efficiency. Clear labeling on terminals simplifies wiring, reducing installation time and errors. Strain relief clamps prevent cable damage from vibration, a common cause of intermittent sensor signals. For maintenance teams, this means faster troubleshooting and fewer unplanned shutdowns, lowering lifecycle costs.
Application Scenarios
In coal-fired power plants, the 132419-01 connects 330103 proximity probes (monitoring turbine shaft vibration) to 3500/33 modules. Its shielding ensures vibration data remains uncorrupted by nearby generators, enabling operators to detect rotor imbalance early and avoid costly turbine failures.
On offshore oil rigs, the module terminates thermocouples (monitoring compressor bearing temperatures) and accelerometers (tracking pump vibration), routing signals to a 3500/42M module. Its corrosion-resistant housing and ATEX certification make it ideal for humid, hazardous environments, ensuring reliable data transmission to prevent seal failures or overheating.
In chemical processing facilities, the 132419-01 organizes RTD wiring from reactor agitators to 3500/60 temperature modules. By centralizing connections, it simplifies cable management in cluttered control cabinets, reducing the risk of wiring errors that could lead to incorrect temperature readings and process disruptions.
Related Models
132419-02 – 16-channel variant of the 132419-01 for larger sensor networks.
125720-01 – Previous generation termination panel with basic shielding, compatible with legacy systems.
330103-00-04-10-02-00 – Proximity probe commonly paired with the 132419-01 for vibration measurements.
132420-01 – High-temperature variant of the 132419-01, rated for -50°C to 100°C environments.
3500/33 – Vibration module that receives signals via the 132419-01 from connected sensors.
Installation and Maintenance
Installing the 132419-01 requires mounting it on a DIN rail or panel in a clean, dry control cabinet, ensuring at least 50 mm of clearance for ventilation. Ground the module to the cabinet (≤4Ω) to minimize electrical noise. Route sensor cables through integrated strain reliefs, securing them to prevent tugging on terminals. Match sensor types to labeled terminals (e.g., RTDs to RTD ports) to avoid signal corruption, and use shielded cables for proximity probes.
For maintenance, inspect the
132419-01 quarterly. Check for loose terminals or damaged cables, tightening connections as needed. Clean dust from the housing with a dry cloth to prevent overheating. Verify that shielding is intact, especially in high-EMI environments like motor control rooms. Replace the module every 8–10 years, or sooner if exposed to severe chemical exposure, to maintain reliable signal transmission.
Product Warranty
The 132419-01 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and premature failure under normal operating conditions. If the module malfunctions, Xiamen Xiongba provides free replacement, ensuring minimal disruption to your machinery monitoring system. Their technical team, experienced in Bently Nevada’s 3500 series, offers guidance on installation and wiring, leveraging direct access to genuine parts. This commitment ensures users trust the 132419-01 for critical sensor termination needs.
